| Camera |
| Image Sensor |
1/3" Progressive Scan CMOS |
| Shutter Speed |
Self-adaptive shutter |
| Lens |
4 mm @ F1.6, viewing angle: 41° (vertical), 76° (horizontal), 90° (diagonal) |
| PT Angle |
Pan: 350°, Tilt: 90° |
| Minimum Illumination |
0.5 Lux @(F1.6, AGC ON), 0 Lux with IR (*data is obtained from EZVIZ laboratories) |
| Lens Mount |
M12 |
| Day & Night |
IR-cut filter with auto switch |
| DNR |
3D DNR |
| WDR |
Digital WDR |
| Black & White Night |
30m / 98ft |
| Video & Audio |
| Max Resolution |
3K (2880 × 1620) |
| Frame Rate |
Self-Adaptive during network transmission |
| Video Compression |
H.265 / H.264 |
| H.265 Type |
Main Profile |
| Video Bit Rate |
Ultra-HD; Hi-Def; Standard. Adaptive bit rate. |
| Audio Bit Rate |
Self-Adaptive |
| Network |
| Wi-Fi Standard |
IEEE802.11a, IEEE802.11b, 802.11g, 802.11n, 802.11ac 802.11ax |
| Frequency Range |
2.4 GHz ~ 2.4835 GHz, 5.15 GHz ~ 5.25 GHz, 5.25 GHz ~ 5.35 GHz, 5.47 GHz ~ 5.725 GHz |
| Channel Bandwidth |
Supports 20MHz (2.4GHz) / Supports 80MHz (5GHz) |
| Security |
WPA / WPA2 / WPA3, WPA-PSK / WPA2-PSK, WPA2-PSK / WPA3-PSK |
| Transmission Rate |
11b: 11Mbps, 11g :54Mbps, 11n :150Mbps, 11ac： 433Mbps, 11ax：600Mbps |
| Wi-Fi Pairing |
AP paring |
| Protocol |
EZVIZ Cloud Proprietary Protocol |
| Interface Protocol |
EZVIZ Cloud Proprietary Protocol |
| Wired Network |
RJ45 × 1 (10 M / 100 M Adaptive Ethernet Port) |
| Functions |
| Smart Alarm |
AI-Powered Human / Vehicle Shape Detection |
| Auto Tracking |
Supports |
| Customized Alert Area |
Supports |
| Two-way Talk |
Supports |
| General Function |
Anti-Flicker, Dual-Stream, Heart Beat, Password Protection, Watermark |
| Storage |
| Local Storage |
Supports microSD card (max. 512 GB) |
| Cloud Storage |
Supports EZVIZ CloudPlay storage (subscription required) |
| General |
| Operating Conditions |
-30°C to 50°C ( -22 °F to 122 °F ) Humidity 95% or less (non-condensing) |
| IP Grade |
Weatherproof Design |
| Power Supply |
DC 12V/1A |
| Power Consumption |
MAX. 12W |
| Dimensions |
100 × 140 × 140 mm (3.94 × 5.51 × 5.51 inch) |
| Packaging Dimensions |
150 × 160 × 194 mm (5.91 × 6.3 × 7.64 inch) |
| Weight |
Net weight:480 g (16.93 oz) With package: 936 g (33.02 oz) |
