Mechanical

• Dimensions : Ø197 x 35 mm (Ø7.76 x 1.38")
• Weight
  • Without mount: 460 g (1.01 lb)
  • With mount: 600 g (1.32 lb)
• Enclosure material Plastic
• Mount material SGCC steel
• Weatherproofing : IP54

Hardware

• Managementinterfaces
  • Ethernet
  • Bluetooth
• Networking interface : (1) GbE RJ45 port
• Button : Factory reset
• LED : White/blue
• Power method : 802.3at PoE+
• Power supply
  • UniFi PoE switch
  • 48V, 0.5A PoE adapter (optional)
• Supported voltage range : 44 to 57VDC
• Max. power consumption : 13W
• Max. TX power
  • 2.4 GHz 22 dBm
  • 5 GHz 26 dBm
• MIMO
  • 2.4 GHz 2 x 2 (UL MU-MIMO)
  • 5 GHz 4 x 4 (DL/UL MU-MIMO)
• Throughput rate
  • 2.4 GHz 573.5 Mbps
  • 5 GHz 4.8 Gbps
• Antenna gain
  • 2.4 GHz 4 dBi
  • 5 GHz 6 dBi
• Mounting : Wall/ceiling (included)
• Operating temperature -30 to 60° C (-22 to 140° F)
• Operating humidity : 5 - 95% noncondensing

Software

• WiFi standards
  • 802.11a/b/g
  • WiFi 4/WiFi 5/WiFi 6
• Wireless security : WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3)
• BSSID : 8 per radio
• VLAN : 802.1Q
• Advanced QoS : Per-user rate limiting
  Guest traffic isolation : Supported
• Concurrent clients : 300+
• Zero wait DFS
  • Yes*
  • *Supportedwithupcomingrmwareversions

Supported DataRates

• 802.11a : 6, 9, 12, 18, 24, 36, 48, 54 Mbps
• 802.11b : 1, 2, 5.5, 11 Mbps
• 802.11g : 6, 9, 12, 18, 24, 36, 48, 54 Mbps
• 802.11n (WiFi 4) : 6.5 Mbps to 600 Mbps (MCS0 - MCS31, HT 20/40)
• 802.11ac (WiFi 5) : 6.5 Mbps to 3.4 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160)
• 802.11ax (WiFi 6) : 7.3 Mbps to 4.8 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160)
