LI120-20B12R2S

Name: LI120-20B12R2S - Communica [Part No: LI120-20B12R2S]
Brand: Mornsun
SKU: LI120-20B12R2S
Price: 641 ZAR
Availability: InStock

SKU: LI120-20B12R2S

BRAND: Mornsun

In Stock
R 737.15_{(inc VAT)}
R 641.00_{(ex VAT)}

Collections: Power

Type: Power Supplies

Category: Din Rail Power Supply, Switch Mode Power Supplies

DIN Rail Metal Case Slim Profile Switch Mode Power Supply Input: 90 ~ 264VAC/127 - 370VDC. Output 12VDC @ 10A 4KVAC Isolation

Slim Profile Switch Mode Power Supply

Overview

LI120-20B12R2S is Mornsun AC-DC converter series featuring a cost-effective, energy efficient green power supply solution for standard DIN-rail mounting. The products offer a high level of stability and immunity to noise for industrial control equipment, machinery, and other industrial equipment in a variety of harsh environments. These light weight AC-DC converters have an extremely compact design and the standard rail installation for space saving. With good EMC performance, compliant with international UL61010, UL508, EN/BS EN 62368 standards for EMC and safety.

Feature

Universal 90 - 264VAC or 127 - 370VDCInput voltage
Accepts AC or DC input (dual-use of same terminal)
Operating ambient temperature range: -20℃to+60℃
High I/O isolation test voltage up to 4000VAC
Low ripple & noise
Output short circuit, over-current, over-voltage, over-temperature protection
DIN rail TS-35/7.5 or 15 mountable
Ultra slim design: suitable for small chassis and narrow space installation
Safety according to UL61010, UL508

Specifications

Type	DIN Rail Single Output
Output Power	120W
Series	LI120-20B
Part Number	LI120-20B12R2S
Mount	DIN-Rail
IP Level	Non-Waterproof
Output Voltage	12V
Output Current	10A

Downloads

Datasheet - LI120-20B12R2S

Additional Information

Device	Power Supply
Type	Slim Profile \| Switch Mode
