DIN Rail Metal Case Three Phase Power supply with Active PFC. input 320 ~ 600VAC/450- 850VDC. Output 48VDC @ 20A
DIN Rail Metal Case Three Phase Power supply
Specifications
Universal 3x320-600VAC or 450-800VDC Input voltage
Active PFC, PF up to 0.94
Operating ambient temperature range: -30℃ to +70℃, 60 ℃ @ 100% load without
Standard DIN-Rail mounting
High efficiency, high reliability
LED indicator for output status
150% peak power lasts for 4s
Output short circuit, over-current, over-voltage, over-temperature protection
Supporting parallel (2+1 current sharing) and series
Fault alarm function, DC OK, constant current
Double-sided conformal coating, salt-spray proof
485 Communication, remote shutdown (PS ON)
Operating altitude up to 5000m
OVC Ⅲ (Safety according to EN61010)
3 years warranty
Safety according to ANSI/ISA 71.04-2013 G3
Safety according to IEC/UL/EN62368, IEC/EN61000, UL/EN61010, CISPR32/EN55032, UL508
Additional Information
Device
Power supply
Type
DIN Rail | Metal Case | Three Phase
Upgrade your power solutions with the LITF960-26B48 DIN Rail Metal Case Three Phase Power Supply. Designed for efficiency and reliability, it delivers 48VDC @ 20A while ensuring safety with multiple protection features. Its robust design supports wide input voltage and extreme temperatures, making it ideal for demanding environments. Trust in high performance and peace of mind with a 3-year warranty.
