LM150-23B55

Name: LM150-23B55 - Communica [Part No: LM150-23B55]
Brand: Mornsun
SKU: LM150-23B55
Price: 549 ZAR
Availability: InStock

SKU: LM150-23B55

BRAND: Mornsun

R 631.35_{(inc VAT)}
R 549.00_{(ex VAT)}

🚚

Delivery time: 2-5 working days for South Africa

✓

In stock - Ready for immediate dispatch

Free shipping for orders over R1,000.00

Collections: Power

Type: Power Supplies

Category: Metal Case Power Supply, Switch Mode Power Supplies

Metal Case Small Outline Switch Mode Power Supply Input: 85 ~ 305VAC/120 - 430VDC. Output 55VDC @ 2,73A. Terminal Block Term. 4KVAC Isolation (LRS-150-55)

Small Outline Switch Mode Power Supply

Overview

LM150-23Bxx series is one of Mornsun’s enclosed AC-DC switching power supply. It features universal AC input and at the same time accepts DC input voltage, cost-effective, low no load power consumption, high efficiency, high reliability and double or reinforced insulation. These converters offer excellent EMC performance and meet IEC/EN61000-4, CISPR32/EN55032, IEC/EN/UL62368, EN60335, GB4943 standards and they are widely used in areas of industrial, LED, street light control, electricity, security, telecommunications, smart home etc.

Feature

Universal 85 - 305VAC or 120 - 430VDC Input voltage
Accepts AC or DC input (dual-use of same terminal)
Operating ambient temperature range: -30℃ to +70℃
Low standby power consumption, high efficiency
High I/O isolation test voltage up to 4000VAC
Low ripple & noise
Output short circuit, over-current, over-voltage, over-temperature protection
IEC/EN/UL62368, EN60335, EN61558, GB4943 safety approved
Over-voltage class Ⅲ (designed to meet EN61558)
Operating altitude up to 5000m

Downloads

Datasheet-LM150-23Bxx

Additional Information

Device	Power Supply
Type	Small \| Outline \| Switch Mode
Size	159.00 x 97.00 x 30.00 mm

Discover the LM150-23B55, a compact and efficient switch mode power supply designed for versatile applications. With a wide input range of 85-305VAC or 120-430VDC, it delivers reliable 55VDC output at 2.73A. Enjoy peace of mind with robust safety features, low standby power consumption, and high efficiency, making it ideal for industrial, telecommunications, and smart home projects.
