LM75-23B12

Name: LM75-23B12 - Communica [Part No: LM75-23B12]
Brand: Mornsun
SKU: LM75-23B12
Price: 352.10 ZAR
Availability: InStock
Rating: 5.00 (1 reviews)

SKU: LM75-23B12

BRAND: Mornsun

R 404.92_{(inc VAT)}
R 352.10_{(ex VAT)}

🚚

Delivery time: 2-5 working days for South Africa

✓

In stock - Ready for immediate dispatch

Free shipping for orders over R1,000.00

Collections: Power

Type: Power Supplies

Category: Metal Case Power Supply, Switch Mode Power Supplies

Metal Case Switch Mode Power Supply Input: 85 ~ 305VAC/120 - 430VDC. Output 12VDC @ 6A. Terminal Block Term. 4KVAC Isolation (LRS-75-12) (Metal Case 12V - 6A)

Small Outline Switch Mode Power Supply

Overview

LM75-23Bxx series is one of Mornsun’s enclosed AC-DC switching power supply. It features universal AC input and at the sametimeacceptsDC input voltage, cost-effective, low no load power consumption, high efficiency, high reliability and double or reinforcedinsulation. Theseconverters offer excellent EMC performance and meet IEC/EN61000-4, CISPR32/EN55032, IEC/UL/EN62368, EN60335, EN61558, GB4943standards and they are widely used in areas of industrial, LED, street light control, electricity, security, telecommunications, smart homeetc

Feature

Universal 85 - 305VAC or 120 - 430VDCInput voltage
Accepts AC or DC input (dual-use of sameterminal)
Operating ambient temperature range: -30℃to+70℃
Low standby power consumption, highefficiency
High I/O isolation test voltage up to 4000VAC
Low ripple & noise
Output short circuit, over-current, over-voltageprotection
Over-voltage class Ⅲ
Operating altitude up to 5000m

Downloads

Datasheet-LM75-23Bxx

Additional Information

Device	Power Supply
Type	Small \| Outline \| Switch Mode
Size	99.00 x 97.00 x 30.00 mm

The LM75-23B12 is a reliable switch mode power supply that delivers 12VDC at 6A, ensuring low standby power consumption and high efficiency. With universal AC/DC input and robust protection features, it’s perfect for industrial, LED, and smart home applications. Enjoy superior performance and peace of mind with its high isolation and compliance with international safety standards.
