Camera
|
|
Image Sensor
|
1/2.8" CMOS
|
|
Pixel
|
4 MP
|
|
Max. Resolution
|
2560 (H) × 1440 (V)
|
|
ROM
|
4 GB
|
|
RAM
|
1 GB
|
|
Electronic Shutter Speed
|
1/1 s–1/30,000 s
|
|
Scanning System
|
Progressive
|
|
Min. Illumination
|
Color: 0.005 lux@F1.6
B/W: 0.0005 lux@F1.6
0 lux(IR light on)
|
|
Illumination Distance
|
50 m (164.04 ft) (white light)
150 m (492.13 ft) (IR)
|
|
Illuminator On/Off Control
|
Zoom Prio; Manual; Smart IR; Off
|
|
Illuminator Number
|
2 (IR)
2 (Dual light fusion)
|
|
Lens
|
|
Focal Length
|
5 mm–125 mm
|
|
Max. Aperture
|
F1.6–F3.6
|
|
Field of View
|
H: 51.9°–3.0°; V: 39.7°–2.2°; D: 63.1°–3.7°
|
|
Optical Zoom
|
25×
|
|
Focus Control
|
Auto; semi-auto; manual
|
|
Close Focus Distance
|
0.1 m–1.5 m (0.33 ft–4.92 ft)
|
|
Iris Control
|
Auto; manual
|
|
DORI Distance
|
Detect
|
Observe
|
Recognize
|
Identify
|
|
2,500 m (8202.10 ft)
|
987.5 m (3239.83 ft)
|
500 m (1640.42 ft)
|
250 m (820.20 ft)
|
|
PTZ
|
|
Pan/Tilt Range
|
Pan: 0° to 360° endless
Tilt: –20° to +90°, auto flip 180°
|
|
Manual Control Speed
|
Pan: 0 °/s–240 °/s
Tilt: 0 °/s–90 °/s
|
|
Preset Speed
|
Pan: 240 °/s
Tilt: 150 °/s
|
|
Preset
|
300
|
|
Tour
|
8 (up to 32 presets per tour)
|
|
Pattern
|
5
|
|
Scan
|
5
|
|
Power-off Memory
|
Yes
|
|
Idle Motion
|
Pattern; Preset; Scan; Tour
|
|
PTZ Protocol
|
DH-SD
|
|
Intelligence
|
|
IVS (Perimeter Protection)
|
Tripwire; intrusion; crossing fence detection; loitering detection; abandoned/missing object; fast moving; parking detection; people gathering; vehicle/human alarm classification; linkage tracking
|
|
Face Detection
|
Supports face detection, face bounding box, capturing snapshots, uploading face snapshots, enhancing face images, and selecting a preferred image among a group of snapshots. Attribute Extraction is also supported, where 6 attributes and 8 expressions can be detected. Face cutout is also offered, where you can cutout one face at a time and customize the size to be a one-inch photo. The supported methods for capturing snapshots are real-time capturing, quality first, and selecting a preferred image among a group of snapshots.
|
|
Auto Tracking
|
Yes
|
|
SMD
|
Yes
|
|
Quick Pick
|
Yes
|
|
Active Deterrence
|
|
Light Warning
|
Red and blue warning light. They can be configured to flash for 5 to 30 seconds with a high, medium or low frequency.
|
|
Sound Warning
|
Customizable sound alarm
|
|
Video
|
|
Video Compression
|
H.264H;H.264B;Smart H.265+;H.264;H.265;MJPEG(Sub Stream);Smart H.264+
|
|
Streaming Capability
|
3 streams
|
|
Resolution
|
4M (2560 × 1440); 3M (2048 × 1536); 3M (2304 × 1296); 1080p (1920 × 1080); 720p (1280 × 720); 1.3M (1280 × 960); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
|
|
Video Frame Rate
|
Main stream: 4M/3M/1080p/1.3M/720p@ (1–25/30 fps)
Sub stream 1: D1/VGA/CIF@ (1–25/30 fps)
Sub stream 2: 1080p/1.3M/720p@ (1–25/30 fps)
|
|
Bit Rate Control
|
CBR/VBR
|
|
Video Bit Rate
|
H264: 96 kbps–14848 kbps
H265: 38 kbps–8960 kbps
|
|
Day/Night
|
Auto (ICR)/Color/B/W
|
|
BLC
|
Yes
|
|
WDR
|
120 dB
|
|
HLC
|
Yes
|
|
White Balance
|
Auto; indoor; outdoor; tracking; manual; sodium lamp; natural light; street lamp
|
|
Gain Control
|
Auto; manual
|
|
Noise Reduction
|
2D NR; 3D NR
|
|
Motion Detection
|
Yes
|
|
Region of Interest (RoI)
|
Yes
|
|
Image Stabilization
|
Electronic (EIS)
|
|
Defog
|
Electronic
|
|
Digital Zoom
|
16×
|
|
Image Rotation
|
180°
|
|
Privacy Masking
|
Up to 24 areas can be set, with up to 8 areas in the same view;
multiple colors available
|
|
S/N Ratio
|
≥55 dB
|
|
Audio
|
|
Audio Compression
|
PCM; G.711a; G.711Mu; G.726; MPEG2-Layer2; G722.1; G729; G723
|
|
Network
|
|
Network Port
|
RJ-45 (10/100 Base-T)
|
|
Network Protocol
|
FTP;RTMP;IPv6;Bonjour;IPv4;DNS;RTCP;PPPoE;NTP;RTP;802.1x;HTTPS;SNMP;TCP/IP;DDNS;UPnP;NFS;ICMP;UDP;IGMP;HTTP;SSL;DHCP;SMTP;Qos;RTSP;ARP
|
|
Interoperability
|
CGI;SDK;ONVIF (Profile S&G&T)
|
|
Streaming Method
|
Unicast/Multicast
|
|
User/Host
|
20 (total bandwidth: 64 M)
|
|
Storage
|
FTP/SFTP; Micro SD card (512 GB); NAS
|
|
Browser
|
IE 9 and later versions
Chrome 41 and later versions
Firefox 50 and later versions
Safari 10 and later versions
|
|
Management Software
|
DSS; DMSS
|
|
Mobile Client
|
iOS; Android
|
|
Certification
|
|
Certifications
|
CE-EMC: EN 55032; EN 61000-3-3; EN 61000-3-2; EN 50130-4; EN 55035
CE-LVD: EN 62368-1
FCC: 47 CFR FCC Part15, Subpart B, NSI C63.4
|
|
Port
|
|
Audio Input
|
1 channel
|
|
Audio Output
|
1 channel
|
|
Alarm Linkage
|
Capture; recording; send email; preset; tour; pattern; alarm digital input; audio; warning light
|
|
Alarm Event
|
Motion/tampering detection; audio detection; network disconnection detection; IP conflict detection; memory card state detection; memory space detection
|
|
Alarm I/O
|
2/1
|
|
Audio I/O
|
1/1
|
|
Power
|
|
Power Supply
|
24 VDC/2.5 A ± 25% (included)
PoE+ (802.3at)
|
|
Power Consumption
|
Basic: 13 W
Max.: 23 W
(illuminator + red and blue warning light + speaker + PTZ working)
|
|
Environment
|
|
Operating Temperature
|
–40 °C to +70 °C (–40 °F to +158 °F)
|
|
Operating Humidity
|
≤95%
|
|
Protection
|
IP66; TVS 6000 V lightning proof; surge protection; voltage transient protection
|
|
Structure
|
|
Product Dimensions
|
325.3 mm × Φ202.0 mm (12.81" × Φ7.95")
|
|
Net Weight
|
4.6 kg (10.14 lb)
|
|
Gross Weight
|
7.13 kg (15.72 lb)
|
