Camera
|
|
|
Image Sensor
|
1/3" Progressive Scan CMOS
|
|
Max. Resolution
|
2688 × 1520
|
|
Min. Illumination
|
Color: 0.001 Lux @ (F1.0, AGC ON); B/W: 0 Lux with IR
|
|
Shutter Time
|
1/3 s – 1/100,000 s
|
|
Angle Adjustment
|
Pan: 0°–360°; Tilt: 0°–90°; Rotate: 0°–360°
|
|
Day & Night
|
IR cut filter
|
|
Lens
|
|
|
Focal Length & FOV
|
2.8 mm: H 100°, V 55°, D 120°
|
|
Lens Type
|
Fixed focal lens, 2.8 mm
|
|
Lens Mount
|
M12
|
|
Iris Type
|
Fixed
|
|
Aperture
|
F1.0
|
|
Depth of Field
|
2.8 mm: 1.9 m–∞
|
|
DORI
|
2.8 mm: D 63 m, O 25 m, R 12 m, I 6 m
|
|
Illuminator
|
|
|
Supplement Light Type
|
IR
|
|
Range
|
Up to 40 m
|
|
Smart Supplement Light
|
Yes
|
|
IR Wavelength
|
850 nm
|
|
Video
|
|
|
Main Stream
|
50 Hz: 25 fps (2688×1520, 1920×1080, 1280×720)
60 Hz: 30 fps (same resolutions)
|
|
Sub-Stream
|
50 Hz: 25 fps (1280×720, 640×480, 640×360)
60 Hz: 30 fps (same)
|
|
Third Stream
|
50 Hz: 10 fps (1920×1080, 1280×720, 640×480, 640×360)
60 Hz: 10 fps (same)
Supported under certain settings
|
|
Video Compression
|
Main: H.265/H.264/H.265+/H.264+
Sub: H.265/H.264/MJPEG
Third: H.265/H.264
|
|
Video Bit Rate
|
32 Kbps – 8 Mbps
|
|
H.264 Profiles
|
Baseline, Main, High
|
|
H.265 Profiles
|
Main
|
|
Bit Rate Control
|
CBR, VBR
|
|
SVC
|
H.264 & H.265
|
|
ROI
|
1 fixed region (main & sub-stream)
|
|
Audio
|
|
|
Compression
|
G.711, G.722.1, G.726, MP2L2, PCM, MP3, AAC-LC
|
|
Type
|
Mono
|
|
Bit Rate
|
64 Kbps (G.711)
16 Kbps (G.722.1/G.726)
32–192 Kbps (MP2L2)
8–320 Kbps (MP3)
16–64 Kbps (AAC-LC)
|
|
Sampling Rate
|
8 / 16 / 32 / 48 kHz
|
|
Noise Filtering
|
Yes
|
|
Network
|
|
|
Protocols
|
TCP/IP, ICMP, HTTP/HTTPS, FTP, DHCP, DNS, DDNS, RTP/RTSP/RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4/IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket(s), SRTP, SFTP
|
|
Simultaneous Live View
|
Up to 6 channels
|
|
API
|
ONVIF (Profile S/T/G), ISAPI, SDK, ISUP
|
|
Users/Hosts
|
Up to 32 (Admin / Operator / User)
|
|
Security
|
Password protection, HTTPS, 802.1X, watermark, IP filter, WSSE, digest auth, RTP/RTSP over HTTPS, TLS 1.1/1.2/1.3, MAC auth, audit log
|
|
Network Storage
|
NAS (NFS, SMB/CIFS), ANR
|
|
Client
|
iVMS-4200, Hik-Connect
|
|
Web Browser
|
IE 10/11 (plug-in)
Chrome 57+, Firefox 52+, Edge 89+ (plug-in free/local service)
|
|
|
|
|
Image Parameters
|
Switchable
|
|
Settings
|
Rotate, saturation, brightness, contrast, sharpness, gain, white balance
|
|
Day/Night Switch
|
Day, Night, Auto, Schedule
|
|
WDR
|
120 dB
|
|
SNR
|
≥ 52 dB
|
|
Enhancements
|
BLC, HLC, 3D DNR, Defog
|
|
Privacy Mask
|
4 programmable polygon masks
|
|
Interface
|
|
|
Ethernet
|
1 × RJ45 10/100 Mbps
|
|
Microphone
|
2 × built-in
|
|
On-Board Storage
|
MicroSD/SDHC/SDXC up to 512 GB
|
|
Speaker
|
Built-in, max. 2 W, 110 dB @ 10 cm
|
|
Reset Key
|
Yes
|
|
Events
|
|
|
Basic Events
|
Motion detection (human/vehicle), tampering, exception
|
|
Smart Events
|
Scene change detection
|
|
Linkage
|
FTP/NAS/memory upload, notify center, email, alarm, recording, capture, audio alert, strobe light
|
|
Deep Learning
|
|
|
Face Capture
|
Yes
|
|
Perimeter Protection
|
Line crossing, intrusion, region enter/exit (human/vehicle filter)
|
|
General
|
|
|
Power
|
12 VDC ±25% (1 A, Max 12 W, Ø5.5 mm plug, reverse polarity)
PoE: IEEE 802.3at, Class 4, Max 16 W
|
|
Material
|
Metal
|
|
Dimensions
|
Ø74.4 × 176.3 mm (Ø2.93" × 6.94")
|
|
Package Dimensions
|
234 × 120 × 117 mm (9.2" × 4.7" × 4.6")
|
|
Weight
|
515 g (1.1 lb)
|
|
Weight (with package)
|
840 g (1.9 lb)
|
|
Storage Conditions
|
-30 °C–60 °C (-22 °F–140 °F), ≤95% RH (non-condensing)
|
|
Operating Conditions
|
-30 °C–60 °C (-22 °F–140 °F), ≤95% RH (non-condensing)
|
|
Languages
|
33 (English, Russian, German, French, Spanish, Italian, Portuguese, Chinese, Japanese, Korean, etc.)
|
|
Functions
|
Heartbeat, mirror, flash log, password reset via email, pixel counter, anti-banding
|
|
Flashing Light
|
/SRB: Red & Blue
/SL: White
|
