Camera
|
|
Image Sensor
|
1/2.8" CMOS
|
|
Pixel
|
2 MP
|
|
Max. Resolution
|
1920 (H) × 1080 (V)
|
|
ROM
|
128 MB
|
|
RAM
|
256 MB
|
|
Electronic Shutter Speed
|
1/3 s–1/30,000 s
|
|
Scanning System
|
Progressive
|
|
Min. Illumination
|
0.005 lux@F1.6 (Color, 30 IRE);
0.0005 lux@F1.6 (B/W, 30 IRE)
0 lux (IR light)
|
|
Illumination Distance
|
100 m (328.08 ft) (IR)
|
|
Illuminator On/Off Control
|
Zoom Prio; manual
|
|
Illuminator Number
|
6 (IR)
|
|
Lens
|
|
Focal Length
|
4.8 mm–120 mm
|
|
Max. Aperture
|
F1.6–F3.5
|
|
Field of View
|
H: 60.6°–3.2°;
V: 34.1°–1.8°;
D: 69.4°–3.7°
|
|
Optical Zoom
|
25×
|
|
Focus Control
|
Auto; semi-auto; manual
|
|
Close Focus Distance
|
0.1 m–2 m (0.33 ft–6.56 ft)
|
|
Iris Control
|
Auto; manual
|
|
DORI Distance
|
Detect
|
Observe
|
Recognize
|
Identify
|
|
1655.2 m (5430.45 ft)
|
653.8 m (2145.01 ft)
|
331.0 m (1085.96 ft)
|
165.5 m (542.98 ft)
|
|
DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool.
|
|
PTZ
|
|
Pan/Tilt Range
|
Pan: 0° to 360° endless;
Tilt: –15° to +90°, auto flip 180°
|
|
Manual Control Speed
|
Pan: 0.1°–200°/s
Tilt: 0.1°–120°/s
|
|
Preset Speed
|
Pan: 240°/s;
Tilt: 200°/s
|
|
Preset
|
300
|
|
Tour
|
8 (up to 32 presets per tour)
|
|
Pattern
|
5
|
|
Scan
|
5
|
|
Power-off Memory
|
Yes
|
|
Idle Motion
|
Pattern;Preset;Scan;Tour
|
|
PTZ Protocol
|
DH-SD
Pelco-P/D (Auto recognition)
|
|
Video
|
|
Resolution
|
1080p (1920 × 1080); 720p (1280 × 720); D1 (704 ×
576/704 × 480)
|
|
Video Frame Rate
|
1080p (25/30 fps); 720p (25/30/50/60 fps)
|
|
Day/Night
|
Yes
|
|
BLC
|
Yes
|
|
WDR
|
120dB
|
|
HLC
|
Yes
|
|
White Balance
|
Auto; indoor; outdoor; tracking; manual; sodium lamp; natural light; street lamp
|
|
Gain Control
|
Auto; manual
|
|
Noise Reduction
|
2D NR; 3D NR
|
|
Defog
|
Electronic
|
|
Digital Zoom
|
16×
|
|
Image Rotation
|
180°
|
|
Privacy Masking
|
Yes
|
|
S/N Ratio
|
≥50 dB
|
|
Function
|
|
CVI Product Output Mode
|
TVI;CVI;CVBS;AHD(CVBS is only used for debugging)
|
|
Certification
|
|
Certifications
|
CE: EN55032/EN55024/EN50130-4
FCC: Part15 subpart B, ANSI C63.4-2014
UL: UL60950-1+CAN/CSA C22.2, No.60950-1
|
|
Port
|
|
Analog Output
|
1 channel (CVBS/CVI output, BNC)
|
|
RS-485
|
1 (baud rate range: 1200 bps–9600 bps)
|
|
Audio Input
|
1 channel (LINE IN, bare wire)
|
|
Alarm Input
|
2 (on-off value input: 0–5 VDC)
|
|
Alarm Output
|
1
|
|
Alarm Linkage
|
Scan; preset; tour; pattern; alarm digital output
|
|
Alarm Event
|
Alarm input
|
|
Power
|
|
Power Supply
|
12 VDC, 3 A ± 10%
|
|
Power Consumption
|
Basic: 10 W
Max.: 22 W (PTZ + illuminator + heater)
|
|
Environment
|
|
Operating Temperature
|
–40 °C to +70 °C (–40 °F to +158 °F)
|
|
Operating Humidity
|
≤95%
|
|
Protection
|
IP66; TVS 6000V lightning proof; surge protection; voltage transient protection
|
|
Structure
|
|
Product Dimensions
|
269.9 mm × Φ160.0 mm (10.63" × Φ6.30")
|
|
Net Weight
|
3.0 kg (6.61 lb)
|
|
Gross Weight
|
4.2 kg (9.26 lb)
|
