Electrical Tester 1000V AC/DC, Resolution:1V, Freq:45hz~66hz Through Open Fork, Resistance:1ω~100kω, AC Current:0.1~200A AC, True RMS, CatIII 1000V
1000V AC/DC Electrical Tester
Features
Save time by seeing voltage and current measurements at the same time
Visual Continuity™ – the screen automatically turns green for continuity, perfect when it’s too loud to hear the beeper
FieldSense™ technology for ac voltage, current and frequency, all without making electrical contact to live voltage
Specifications
Function
FieldSense ac voltage
Requires test leads
No
Range
1000 V
Resolution
1 V
Accuracy
±(3 % + 3 counts) 45 Hz - 66 Hz[1] [2]
FieldSense ac current
Requires test leads
No
Range
200.0 A
Resolution
0.1 A
Accuracy
±(3 % + 3 counts) 45 Hz - 66 Hz
FieldSense frequency (Hz)
Requires test leads
No
Range
45 Hz – 66 Hz
Resolution
1 Hz
Accuracy
±(1 % + 2 counts)
Volts ac
Requires test leads
Yes
Range
1000 V
Resolution
1 V
Accuracy
±(1.5 % + 2 counts) 45 Hz - 66 Hz
Volts dc
Requires test leads
Yes
Range
1000 V
Resolution
1 V
Accuracy
±(1 % + 2 counts)
Resistance
Requires test leads (all ranges)
Yes
Range
2000 Ω
Resolution
1 Ω
Range
20.00 kΩ
Resolution
0.01 kΩ
Range
100.0 kΩ
Resolution
0.1 kΩ
Accuracy (all ranges)
±(1 % + 2 counts)
Accuracy[1]: ± ( [ % of reading] + [number of least significant digits] ). Accuracy is specified for 1 year after calibration, at 18 °C to 28 °C (64 °F to 82 °F) with relative humidity to 90 %. AC conversions are ac-coupled, RMS responding.
Accuracy[2]: FieldSense specified from 16V to 1000V.
General Specifications
Calibration
1-year calibration cycle
Dimensions
61 mm x 259 mm x 43 mm
Weight
0.35 kg (0.78 lb)
Fork opening
17.8 mm (0.7”)
Temperature Operating: Storage:
-10 °C to +50 °C (14 °F to 122 °F) -30 °C to +60 °C (-22 °F to +140 °F)
Altitude Operating: Storage:
2,000 m (6,562 feet) 10,000 m (32,808 feet)
Relative Humidity
0 % to 90 %, 5 °C to 30 °C (41 °F to 86 °F) 0 % to 75 %, 30°C to 40 °C (86 °F to 104 °F) 0 % to 45 %, 40°C to 50 °C (104 °F to 122 °F)
Battery Type: Life:
2x AA (IEC LR6) 360 hour continuous, typical is 200 hour using the FieldSense function
Temperature coefficient
0.1 x (specified accuracy) / °C for <18°C or >28 °C (< 64.4 °F or > 82.4 °F)
Discover the FLUKE T6-1000 PRO, the ultimate 1000V AC/DC electrical tester designed for professionals. With FieldSense technology, visualize voltage and current simultaneously, ensuring safety and efficiency in your measurements. Its Visual Continuity feature provides instant alerts, making it perfect for noisy environments. Elevate your testing capabilities with precision and ease, and never compromise on safety again!
