Clamp Meter Digital 750V AC/1000 DC 600A AC Resistance 60M, CAP:60nF~60mF, FREQ, Temp, Display Count 6000, Auto Range, Jaw Capacity 30mm, True RMS, Diode, NCV, V.F.C, Auto Power OFF, Continuity Buzzer, Low Bat Indication, CATII 1000V CATIII 600V
750V Digital Clamp Meter
Specifications
AC current (A) : 600A ±(2.5%+5)
AC current frequency response : 40~400Hz
AC voltage frequency response : 600A ±(2.5%+5)
DC current (A) : 750V ±(1.2%+5)
AC voltage (V) : 40~400Hz
DC voltage (V) : 1000V ±(0.8%+1)
Resistance (Ω) : 60MΩ ±(1%+2)
Capacitance (F) : 60mF ±(4%+5)
Frequency (Hz) : 10Hz~1MHz ±(0.1%+4)
Temperature
-40°C~1000°C ±(2%+5)
-40°F~1832°F : ±(2%+10)
Display count : 6000
Auto range : Yes
Jaw opening : 30mm
True RMS : Yes
Diode : Around 3.0V : Yes
V.F.C. : Yes
NCV : Yes
Data hold : Yes
Relative mode : Yes
MAX/MIN : Yes
LCD backlight : Yes
Inrush current : Yes
Analog bar graph : Yes
Flashlight : Yes
Auto power off : Yes
Continuity buzzer : Yes
Low battery indication : ≤3.6V : Yes
Input protection : Yes
Input impedance for DCV : ≥10MΩ : Yes
Power : 1.5V battery (R03) x 3
Display : 38mm x 24mm
Product color : Red and grey
Product net weight : UT216A: 280g; UT216B/C/D: 231.7g
Product size : 220mm x 75mm x 40mm
Standard accessories : Batteries, test leads, point contact temperature probe
Additional Information
Device
Clamp Meter
Type
750V | Digital
The UNI-T UT216C Digital Clamp Meter is your ultimate tool for accurate measurements, featuring 750V AC/DC, 600A capacity, and True RMS technology. With auto-ranging, a 6000 display count, and essential functions like NCV and continuity testing, this clamp meter ensures precision and safety for all your electrical tasks. Upgrade your toolkit today for reliable performance and ease of use!
