88545 Plug 32W Rows A & C (RAC) Straight Wire Wrap
Plug Connector
Feature(s)
- 32-way DIN 41612 male plug
- Straight (vertical) PCB mounting
- Rows A & C (RAC) populated
- Wire-wrap termination for secure backplane wiring
- 5.08 mm contact pitch
- 13 mm wire-wrap pins
- Gold-plated contacts for reliable electrical performance
- Rugged glass-filled thermoplastic housing
- Suitable for Eurocard and industrial backplane systems
Specifications
- Product Type: DIN 41612 Eurocard Plug Connector
- Model Number: 88545
- Connector Style: Straight (Vertical)
- Standard: DIN 41612 / IEC 60603-2
- Connector Type: Male (Plug)
- Number of Contacts: 32
- Contact Arrangement: Rows A & C (RAC)
- Contact Configuration: 2 × 16
- Mounting Type: Through-Hole PCB Mount
- Orientation: Straight (Vertical)
- Termination Type: Wire Wrap
- Contact Pitch: 5.08 mm
- Row Spacing: 5.08 mm
- Wire Wrap Pin Length: 13 mm
- Contact Material: Copper Alloy
- Contact Plating:
- Gold-plated mating contacts
- Tin-plated wire-wrap tails
- Housing Material: Glass-Filled Thermoplastic (PBT)
- Housing Color: Grey
- Rated Current: Up to 6 A per Contact
- Rated Voltage: 125–250 V AC (application dependent)
- Contact Resistance: ≤15 mΩ
- Insulation Resistance: ≥1,000 MΩ
- Dielectric Withstanding Voltage: 1,000 V AC
- Mating Cycles: ≥400
- Operating Temperature: -55°C to +125°C
- Flammability Rating: UL94 V-0
- Compliance:
- DIN 41612
- IEC 60603-2
- RoHS Compliant
Additional Information
| Device |
Connector |
| Type |
DIN41612 | Plug | Connector |
| Gender |
Male |
| No. of Contacts |
32 |
| No. of Pins |
32 |
| Termination |
Straight Wire Wrap |
| Row Positions |
Rows A,C |
Discover the 88545 Plug 32W Rows A & C, a robust 32-way DIN 41612 male connector designed for secure backplane wiring. With gold-plated contacts and a durable thermoplastic housing, this plug ensures reliable electrical performance and longevity. Ideal for Eurocard and industrial applications, it supports high currents and voltages while maintaining excellent insulation resistance. Elevate your connectivity solutions with this premium plug connector!
