Hikvision 16CH Embedded Plug & Play NVR H.264, HDMI/VGA O/P:1-CH: Resolution:1920x1080P, 1080P /UXGA /720P /VGA /4CIF /DCIF /2CIF /CIF /QCIF, Capability: 8-CH@4CIF, 8-ch@720P, 1 x SATA Interface upto 4TB, 1 x RJ45 10/100Mbs, 2 x USB2.0 (285×210×45mm)
16CH Embedded Plug & Play NVR
Feature(s)
- Third-party network cameras supported
- Up to 2 Megapixels resolution recording
- HDMI and VGA output at up to 1920×1080P resolution
- HDD quota and group management
- 4/8 independent network interfaces for built-in switch
Specifications
Video/Audio input
- Video input : 16-ch
- Two-way audio input : 1-ch, RCA (2.0 Vp-p, 1kΩ)
Network
- Incoming bandwidth : 100Mbps
- Outgoing bandwidth : 40Mbps
- Remote connection : 128
Video/Audio output
- HDMI/VGA output : 1-ch, resolution : 1920 × 1080P /60Hz, 1280 × 1024 /60Hz, 1280 × 720 /60Hz, 1024 × 768 /60Hz
- Audio output : 1-ch, RCA (Linear, 1kΩ)
Decoding
- Live view / Playback resolution : 1080P /UXGA /720P /VGA /4CIF /DCIF /2CIF /CIF /QCIF
- Capability : 8-ch@4CIF, 8-ch@720P, 4-ch@1080P
Hard disk
- SATA : 1 SATA interface for 1 HDD
- Capacity : Up to 4TB for each disk
External interface
- Network interface : 1 RJ-45 10 / 100 Mbps selfadaptive Ethernet interface
- Built-in switch network interface(DS7104/08/16NI-SN/N supported : 8 independent 10 /100 Mbps Ethernet interfaces
- USB interface : 2 × USB 2.0
Others
- Power supply : 12V DC
- Consumption (without
- hard disk and PoE) : ≤ 15 W
- Working temperature : -10 ºC ~ +55 ºC (+14 ºF~ + 131 ºF)
- Working humidity : 10 % ~ 90 %
- Chassis : 1U chassis
- Dimensions(W × D × H) : 285 × 210 × 45 mm
- Weight : 1 Kg ( without hard disk)
Downloads
Additional Information
| Device |
NVR |
| Type |
16CH | Embedded | Plug & Play |
Upgrade your security system with the Hikvision HKV DS-7116NI-SN, a powerful 16CH Plug & Play NVR. Enjoy high-definition recordings up to 1080P, seamless integration with third-party cameras, and extensive storage options of up to 4TB. Perfect for home or business security, this NVR ensures reliable monitoring and playback capabilities, enhancing your peace of mind.
