Image sensor
|
1/2.7" Progressive Scan CMOS
|
|
Resolution
|
4 Mpx (2560x1440)
|
|
Main Stream rate
|
25 fps (2560x1440, 1920x1080, 1280x720)
|
|
Extra Stream rate
|
25 fps (768x432)
|
|
Compression
|
H.265, H.264, MJPEG
|
|
Bitrate
|
32 Kbps at 8 Mbps
|
|
Lens
|
2.8 mm fixed lens
|
|
Viewing angle
|
H: 94°, V: 49°, D: 114°
|
|
Minimum illumination
|
Colour: 0.005 Lux @ (F1.6, AGC ON)
B/W: 0 Lux with IR (range 30 m)
|
|
Day/Night
|
Removable mechanical ICR filter
|
|
Motion Detection
|
Motion detection 2.0 with human and vehicle classification applied in motion detection.
|
|
Image improvements
|
DWDR, 3D-NR, BLC, HLC, Mirror effect, Privacy masking
|
|
Audio
|
Built-in microphone and speaker
|
|
Audio Compression
|
G.711ulaw/AAC-LC
|
|
Audio bitrate
|
64 Kbps (G.711ulaw)/16 a 64 Kbps (AAC-LC)
|
|
Environmental noise reduction
|
Yes
|
|
Network interface
|
Ethernet 10/100 BaseT
Wifi IEEE 802.11b/g/n/ax
|
|
Internal memory
|
MicroSD card slot up to 512 GB
|
|
Power
|
DC 12 V / 0.5 A / 6 W max.
|
|
Temp. operation
|
-30º C ~ +60º C
|
|
Degree of protection
|
Weatherproof IP66
|
|
Dimensions
|
67.4 mm (H) x 113.9 mm (W) x 260.9 mm (D)
|
|
Weight
|
305 g
|
|
PT Dome Camera
|
|
Brand
|
Hikvision
|
|
Image sensor
|
1/2.7" Progressive Scan CMOS
|
|
Resolution
|
4 Mpx (2560x1440)
|
|
Main Stream rate
|
25 fps (2560x1440, 1920x1080, 1280x720)
|
|
Extra Stream rate
|
25 fps (768x432)
|
|
Bitrate
|
32 Kbps at 8 Mbps
|
|
Compression
|
H.265, H.264, MJPEG
|
|
Lens
|
2.8 mm fixed lens
|
|
Viewing angle
|
H: 94°, V: 49°, D: 114°
|
|
Minimum illumination
|
Colour: 0.005 Lux @(F1.6, AGC ON)
0 Lux with IR
|
|
Supplementary lighting
|
Hybrid light:
IR range of 25 m
White light range 25 m
|
|
Day/Night
|
Removable mechanical ICR filter
|
|
Pan/Tilt Range
|
Horizontal: 0~345°, Vertical: 0°~80°
|
|
Motion Detection
|
Motion detection 2.0 with human and vehicle classification applied in motion detection.
|
|
Image improvements
|
DWDR, 3D-NR, BLC, HLC, Privacy masking
|
|
Audio
|
Built-in microphone and speaker
|
|
Audio Compression
|
G.711ulaw/AAC-LC
|
|
Audio bitrate
|
64 Kbps (G.711ulaw)/16 a 64 Kbps (AAC-LC)
|
|
Environmental noise reduction
|
Yes
|
|
Internal memory
|
MicroSD card slot up to 512 GB
|
|
Network interface
|
Ethernet 10/100 BaseT
Wifi IEEE 802.11b/g/n/ax
|
|
Power
|
DC 12 V / 0.75 A / 9 W max.
|
|
Temp. operation
|
-10º C ~ +40º C
|
|
Degree of protection
|
Weatherproof IP66
|
|
Dimensions
|
124 mm (Ø) x 119 mm (H)
|
|
Weight
|
600 g
|
|
NVR
|
|
Brand
|
Hikvision
|
|
Inputs for IP cameras
|
LAN port up to 4 channels
Wifi IEEE 802.11b/g/n/ax
|
|
Wi-Fi frequency
|
2.4 GHz
|
|
Wi-Fi transmission speed
|
150 Mbps
|
|
Video compression format
|
H.265, H.264, MJPEG
|
|
Total bandwidth
|
20 Mbps downstream / 20 Mbps upstream
|
|
Main Stream recording
|
6 Mpx /5 Mpx / 4 Mpx / 3 Mpx / 1080p / UXGA / 720p / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF
|
|
Simultaneous multifunction
|
Pentaplex: Live, Recording, Playback, Backup and Remote Access
|
|
Recording method
|
Manual, programmed, motion detection
|
|
Internal memory
|
1 HDD SATA
|
|
Remote access
|
Web Browser, Hik-Connect Smartphone App, PC Software iVMS-4200 and Hik-Central
|
|
Temp. operation
|
-10º C ~ +55º C
|
|
Power
|
DC 12V / 6W
|
|
Dimensions
|
26 (H) x 163 (W) x 125 (D) mm
|
|
Weight
|
500 g (without hard disk)
|
