SME SENSOR SHIELD ARD COMPATIBLE

SKU: SME SENSOR SHIELD ARD COMPATIBLE

BRAND: Itead Studio


Compatible with Arduino Sensor Shield to connect various types of Electronic Brick Modules 61x55.46x1.6mm

Overview

Compatible with Arduino sensor shield is specifically designed for Arduino board to connect to various types of electronic brick modules. The latest version of shield can support electronic bricks with 3-wire and 4-wire communication, and it is compatible with the mainstream two interfaces of electronic bricks in the market: 2.0mm 4-pin grove interface and 2.54mm 3-pin interface. In addition, the shield is equipped with XBee interface for users to connect it with various external wireless modules which are compatible with XBee module interface. When working together with BTBee Pro, it can be used as a board.

What is an Electronic Brick ?

An electronic brick is an electronic module which can be assembled like Lego bricks simply by plugging in and pulling out. Compared to traditional universal boards and circuit modules assembled with various electronic components, electronic brick has standardized interfaces, plug and play, simplifying construction of prototype circuit on one’s own. There are many types of electronic bricks, and we provide more than twenty types with different functions including buttons, sensors, Bluetooth modules, etc, whose functions cover from sensor to motor drive, from Ethernet to wireless communication via Bluetooth, and so on. We will continue to add more types to meet the various needs of different projects.

Features

  • Compatible with Arduino
  • 20 digital input/output pins
  • 6 analog inputs
  • 1 UARTs/1 IIC

Specifications

  • Version 5.0
  • Shield Functions : Prototype
  • Stackable : Yes
  • Weight 60.00g
  • PCB Size : 61.0mm X 55.46mm X 1.6mm
  • Working voltage : 3.3/5V DC
  • Operating voltage : 3.3/5V DC
  • Compatible interfaces : 2.54 3/4-pin interface, Grove 4-pin interface(1) and XBee interface

Downloads

Additional Information

Keywords shield, sensor
Device Sensor Shield
Type Development Platform | Shields
