TP-LINK 10 Port 10/100/1000Mbs Desktop Switch with 8 Port PoE+, Auto MDI/MDIX, 4K, Auto-learning, (209×126×26mm), Unmanaged
10 Port 10/100/1000Mbs Desktop Switch
Overview
The TL-SG1210P provides 9 10/100/1000Mbps RJ45 ports and 1 Gigabit SFP port. Port 1 to port 8 of
the switch support IEEE 802.3af/at compliant PDs with up tp 30 W for each PoE port and total PoE
power budget of 63 W*. The TL-SG1210P is an unmanaged switch with desktop design, outstanding
performance and quality, which is a great selection for expanding your network.
Features
Power over Ethernet
- 8 IEEE 802.3af/at compliant PoE+ ports, with a total PoE power budget of 63 W*
- Flexible deployment for PoE suppoted devices such as wireless access points (APs), IP cameras and IP phones
- Designed to use a single Ethernet cable for both data and power transmission, lowering infrastructure costs
Gigabit Expansion Solution
- 9 10/100/1000Mbps RJ45 ports and 1 Gigabit SFP port provide up to 20 Gbps Switching Capacity
- IEEE 802.3x flow control provides reliable data transfer
Highlight Performance
- 802.1p and DSCP QoS ensures smooth traffic
- IGMP Snooping optimizes multicast applications
- Fanless design ensures quiet operation
Easy to Use
- Just plug & play, no configuration required
- Auto MDI/MDIX eliminates the need for crossover cables
- Auto-negotiation intelligently adjusts for compatibility and optimal performance
Specifications
- Standards : IEEE 802.3i, 802.3u, 802.3ab, 802.3x, 802.3af, 802.3at, 802.3z, 802.1p
- Network Ports
- 8 PoE+ 10/100/1000 Mbps RJ45 Ports
- 1 10/100/1000 Mbps RJ45 Port
- 1 Gigabit SFP Slot
- Network Media(Cable)
- 10Base-T: UTP category 3, 4, 5 cable (maximum 100 m)
- EIA/TIA-568 100 Ω STP (maximum 100 m)
- 100Base-TX: UTP category 5, 5e or above cable (maximum 100 m)
- EIA/TIA-568 100 Ω STP (maximum 100 m)
- 1000Base-T: UTP category 5, 5e, 6 or above cable(maximum 100 m)
- EIA/TIA-568 100 Ω STP (maximum 100 m)
- 1000BASE-X MMF, SMF
- PoE
- PoE Standard: 802.3af/at
- PoE Ports 1-8, up to 30 W per port
- PoE Power Budget 63 W*
- Auto Negotiation : YES
- Auto MDI/MDIX : YES
- Max Power Consumption
- 7.11 W (220/50 Hz. no PD connected)
- 78.13 W (220/50 Hz. with 63 W PD connected)
- Max Heat Dissipation
- 24.25 BTU/h (no PD connected)
- 266.42 BTU/h (with 63 W PD connected)
- Forwarding Mode : Store and Forward
- Switch Capacity : 20 Gbps
- MAC Address Table : 4K, Auto-learning, Auto-aging
- Flow Control : YES
- Fanless : YES
- LED : Power, Link/Act, PoE Status, PoE MAX
- Dimensions : 8.2 x 5.0 x 1.0 in. (209 × 126 × 26 mm)
- Certifecation : CE, FCC
- Operating Temperature : 0°C to 40 °C (32 °F to 104°F )
- Storage Temperature : -40 °C to 70 °C (-40 °F to 158°F )
- Operating Humidity 1: 0% to 90% non-condensing
- Storage Humidity : 5% to 90% non-condensing
Downloads
Additional Information
| Device |
Switch |
| Type |
10 Port | 10/100/1000Mbs | Desktop |
