USR DR302 DIN RAL RS485-ETHERNET

Name: USR DR302 DIN RAL RS485-ETHERNET - Communica [Part No: USR DR302 DIN RAL RS485-ETHERNET]
Brand: UsrIoT
SKU: USR DR302 DIN RAL RS485-ETHERNET
Price: 530 ZAR
Availability: InStock

SKU: USR DR302 DIN RAL RS485-ETHERNET

BRAND: UsrIoT

R 609.50_{(inc VAT)}
R 530.00_{(ex VAT)}

🚚

Delivery time: 2-5 working days for South Africa

✓

In stock - Ready for immediate dispatch

Free shipping for orders over ZAR 1,000.00

Collections: Computing & Peripherals

Type: Industrial IoT Wi-fi Solutions

Category: Ethernet Media Converters

An Industrial Single DIN Rail RS485 to Ethernet Converter, Which can Transmit Data Transparently between TCP/IP and RS485

Single DIN Rail RS485 to Ethernet Converter

Overview

Din Rail RS485 to Ethernet Converters USR-DR302 can transmit data transparently between TCP/IP and RS485, which are widespread required in industrial automation. USR-DR302 is a Din Rail RS485 to Ethernet Converter, which can transmits data transparently between TCP/IP and RS485. Via web-page or software, rs485 to Ethernet Converter can realize serial data and TCP/IP data package transparent transmission.

Features

Simple configuration and easy to use
Compact, Light Weight
Supports TCP server/client, UDP server/client, Virtual COM
RS485 Port, Industrial Grade
Standard DIN-rail mounting
Modbus RTU to Modbus TCP
single RS485 to ethernet converters,RS485 to tcp ip is widespread required in industrial automation.

Specifications

Categories	Cellular & Network Communication
Manufacturer/Brand	USR IOT
Series	USR-DR
Ethernet ports	1
Ethernet Protocols	10/100 Mbps
Serial Standard	RS485
Comm. Method	Serial
Comm. Protocol	ARP, DHCP, ICMP, IPV4, Static IP, TCP/IP, UDP
Supply Voltage	5-36 Vdc
Operating Temperature	-40° to 185°F, -40° to 85°C
Width (in)	1.10
Depth (in)	2.55
Height (in)	4.32
Width (mm)	28.00
Depth (mm)	64.71
Height (mm)	109.66
Weight (kg)	0.363
Weight (lbs)	0.80
Safety Approvals	FCC, RoHS
Safety Standards	CE
Non-Stock Lead Time	2 Weeks

Downloads

Additional Information

Device	Converter
Type	Single \| DIN Rail \| RS485 to Ethernet
References	USR IOT

Upgrade your industrial automation with the USR DR302 DIN RAL RS485-Ethernet Converter. This compact device enables seamless data transmission between TCP/IP and RS485, ensuring reliable communication in any environment. With easy configuration and robust performance, it's the perfect solution for enhancing connectivity in your projects.
