USR N540 4-PORT SERIAL-ETHERNET

SKU: USR N540 4-PORT SERIAL-ETHERNET

BRAND: Usr IoT


An Industrial 4 Port Ethernet Device Server with BI-Directional Transparent Transmission Between RS232/RS485/RS422 and Network.

4 Port Ethernet Device Server

Features

  • USR IOT's serial to IP Converters USR-N540 can realize bi-directional transparent transmission between RS232/RS485/RS422 and network
  • 4-port RS-232/422/485 Serial to IP Converter
  • Power supply accepts wide voltage input range DC 9-36 Vdc
  • Support TCP server/client, UDP server/client,https client, Virtual COM
  • Support Modbus RTU to Modbus TCP
  • Support flow control CTS/RTS, XON/XOFF
  • Support 4 RS-232, RS-485/422 3IN1 serial port to 1 10/100Base-T(X) self-adaptive Ethernet interface
  • Configuration via Web Server page, AT commands, and Windows Utility

Specifications

Categories Cellular & Network Communication
Manufacturer/Brand USR IOT
Ethernet ports LAN, WAN
Ethernet Protocols 10/100 Mbps
Serial Standard RS232, RS422, RS485
Comm. Method Serial
Comm. Protocol ARP, DHCP, DNS, Ethernet, HTTP, HTTPD Client, ICMP, IP, TCP, UDP, Web socket
Supply Voltage 9~24 Vdc
Operating Temperature -40° to 185°F, -40° to 85°C
Width (in) 8.74
Depth (in) 4.80
Height (in) 1.14
Width (mm) 222.00
Depth (mm) 122.00
Height (mm) 29.00
Weight (kg) 1.360
Weight (lbs) 3.00
Safety CE, FCC, RoHS

Downloads

Additional Information

Device Device Server
Type 4 Port | Ethernet
