SwitchBox can be connected with virtually all electrical devices providing on / off switching functionality as well as the ability to check the status of all controlled devices.

All wBox devices (with µWiFi technology) can communicate with each other, allowing switchBox to control other devices, e.g. When paired with a shutterBox unit, the user can easily configure the device by pressing a single button to close the roller shutters of your house.

• Supply Voltage : 230V
• Power Consumption : Less than 1W
• Outputs number : 2
• Outputs Type : Relay
• Maximum Current (total) : 5A
• Maximum Current (channel) : 5A
• Max load : 1000W
• Inputs Number : 2
• Inputs Type : Logical, to N
• Inputs Voltage : 230V
• Housing : Made of polyurethane composition not containing halogens, self-extinguishing for thermal class B (130 °C)
• Protection Rating : IP20
• Dimensions : 42 x 39 x 24 mm
• Transmission : bi-directional with confirmation, encrypted
• Transmission Frequency : 2.4GHz
• Communication standard : μWiFi, compatible with WiFi
• Communication Mode : direct connection (as an Access Point), WiFi connection via a standard router, connection with access from anywhere in the world (only Internet access required)
• You can control : Apple iPhone, Apple iPad, iPad Mini, Android, computers and mobile devices supporting HTML5
• Encryption : WPA2-PSK and Authenticated Encryption (AEAD)
