BMT IR OBSTACLE AVOIDANCE SENSOR

Name: BMT IR OBSTACLE AVOIDANCE SENSOR - Communica [Part No: BMT IR OBSTACLE AVOIDANCE SENSOR]
Brand: Communica
SKU: BMT IR OBSTACLE AVOIDANCE SENSOR
Price: 11.30 ZAR
Availability: InStock
Rating: 5.00 (1 reviews)

SKU: BMT IR OBSTACLE AVOIDANCE SENSOR

BRAND: Communica

R 13.00_{(inc VAT)}
R 11.30_{(ex VAT)}

🚚

Delivery time: 2-5 working days for South Africa

✓

In stock - Ready for immediate dispatch

Free shipping for orders over R1,000.00

Collections: DIY Kits, IoT, Internet of things

Type: Motors, Motor Drivers & Controllers

Category: Iot, Obstacle Avoidance Sensor Module

Infrared Photoelectric Reflection Intelligent Car Obstacle Avoidance Sensor Module

Obstacle Avoidance Sensor Module

Overview

This sensor module have great adaptive capability of the ambient light, having a pair of infrared transmitter and the receiver tube, the infrared emitting tube to emit a certain frequency, encounters an obstacle detection direction (reflecting surface), infrared reflected back to the receiver tube receiving, after a comparator circuit processing, the green LED lights up, while the signal output will output digital signal (a low-level signal), through the potentiometer knob to adjust the detection distance, the effective distance range 2 ~ 80cm working voltage of 3.3V-5V. The detection range of the sensor can be adjusted by the potentiometer, with little interference, easy to assemble, easy to use features, can be widely used robot obstacle avoidance, obstacle avoidance car assembly line count and black-and-white line tracking and many other occasions.

Features

When the module detects obstacles in front of the signal, the circuit board green indicator light level, while the OUT port continuous output low-level signals, the module detects a distance of 2 ~ 80cm, detection angle 35 °, the detection distance can be potential adjustment with adjustment potentiometer clockwise, the increase in detection distance; counterclockwise adjustment potentiometer, the detection distance decreased.
The sensor active infrared reflection detection, target reflectivity and shape of the detection distance of the key. The black minimum detection range, white maximum; small area object distance is small, a large area from the large.
The sensor module output port OUT can be directly connected with the microcontroller IO port can also be driven directly to a 5V relay; Connection: VCC-VCC; GND-GND; OUT-IO
The comparator using LM393, stable;
3-5V DC power supply module can be used. When the power is turned on, the red power LED is lit;
With the screw holes of 3mm, easy to install;
Board size : 3.1x1.5cm
Each module in the delivery has threshold comparator voltage adjustable via potentiometer, special circumstances, please do not adjust the potentiometer.

Specifications

Interface(3-wire)

VCC external 3.3V-5V Voltage (can be directly connected with the a 5V microcontroller and 3.3V microcontroller)
GND external GND
OUT board digital output interface (0 and 1)
LEDs : Power Indicator, Switch Indictor

Additional Information

Device	Sensor Module
Type	Obstacle \| Avoidance

Enhance your robotics projects with the BMT IR Obstacle Avoidance Sensor. This intelligent module features adjustable detection from 2 to 80cm, ensuring reliable obstacle detection in various settings. Easy to install and compatible with microcontrollers, it helps you build smarter, safer devices effortlessly. Perfect for robotics, line tracking, and automation tasks!
