The Nemlink cards provide a convenient ethernet interface for the Druid two-zone energizers and the Druid FG controller to be distributed over standard
TCP/IP ethernet networks.

Ethernet connectivity allows the RS-485 LAN to operate over an IP network architecture including 802.3i (10baseT) and 802.3U (100baseT) switching and routing equipment.

Wireless communications can also be achieved using a wireless router and ethernet / 802.11 point-to-point RF solutions.

• Compatible with the Druid two-zone energizers and Druid FG7 controller
• Fits inside the Druid two-zone energizer enclosure
• Provides electrical isolation between devices on the network
• User-configurable IP settings and baud rate (the D2x network uses a 19 200 baud rate)
• Enables the use of existing IP Network infrastructure, saving wiring time and costs

• Size : L140mm x W55mm x H20mm
• Weight : 45g
• Operating environment : -20°C – 55°C @ 10% – 90%RH (non-condensing)
• Power supply : 10V – 15V DC
• Current consumption : 80mA
• Connector : RJ45

1. Datasheet - EF DRUID NEMLINK CARD
