Capacity

8TB

Interface

SATA 6 Gb/s

Recording Technology

CMR

Drive Design

Air

Features & Performance

Drive Bays Supported

16

AI Channels

32

AI Real Time Capture Events/Sec

Up to 120

AI Real Time Compare Events/Sec

Up to 96

HD Cameras Supported

Up to 64

RV Sensors

Yes

Max Sustained Transfer Rate OD

235MB/s

Cache

256MB

Reliability / Data Integrity

Tarnish Resistant

Yes

Load / Unload Cycles

300,000

Non-recoverable Read Errors Rate, Max

1 per 10E15

Power-On Hours per year

8,760

Workload Rate Limit (WRL)

550

Mean Time Between Failures (MTBF)

2,000,000Hr

Power Management

Startup Current (Typical)

1.8A

Average Operating Power

8.73W

Idling Average

7.5W

Standby Mode / Sleep Mode, Typical

0.96W / 0.96W

Voltage Tolerance (5 V)

10%/-5%

Voltage Tolerance (12 V)

±10%

Physical

Dimensions

26.11mm x 101.85mm x 146.99mm

Weight

716g
