HF105F-1-024DT-1HS

SKU: HF105F-1-024DT-1HS

BRAND: Hongfa


Miniature High Power Relay, Form 1A, VCoil= 24V DC, IMax Switching= 40A , RCoil= 660Ω, PCB, in Vertical Case

Overview

Features

Specification



  • Plastic Sealed
  • Without Pin No. 6
  • Insulation Class B
Model HF105F-1-024DT-1HS
Brand Hongfa
Contact Form Form 1A
Size Category Mini
Size 32.2x27x20.1mm
Termination PCB
Coil Rated Voltage 24V
AC/DC Voltage DC
Max. Switching Current 40A
Electrical Rating 30A | 240VAC
Coil Power 900mW Power
Coil Resistance 660Ω
Isolation Voltage 4KV
Approvals UL/CUL
Contact Material AgCdO
No. of Pins 5 Pin(s)
No. of Poles 1 Pole(s)
