HKV DS-2CD2T87G2P-LSU/SL (4MM)

SKU: HKV DS-2CD2T87G2P-LSU/SL (4MM)

BRAND: Hikvision


Hikvision ColorVu Bullet Network Camera 8MP 4mm Lens, Upto 40m, 2×1/1.8" Progressive Scan CMOS, 5120×1440, 32Kbps to 16Mbps, WDR, 1XRJ45 10M/100M Self-adaptive Ethernet Port, Pan:0°~355°, Tilt:-0°~90°, H.264/H.265, Upto 512GB Card Slot, IP67

ColorVu Bullet Network Camera

Overview

Hikvision ColorVu technology provides 24/7 vivid colorful images with F1.0 advanced lenses, high performance sensors and friendly lighting. F1.0 super-aperture collects more light to produce brighter images. Advanced sensor technology can vastly improve the utilization of available light.

Feature(s)

  • High quality imaging with 8 MP resolution
  • One image that presents all the scenes covered by the camera
  • 24/7 colorful imaging
  • Efficient H.265+ compression technology
  • Clear imaging against strong back light due to 130 dB WDR technology
  • Focus on human and vehicle classification based on deep learning
  • Active strobe light and audio alarm to warn intruders off
  • Water and dust resistant (IP67)

Specifications

Camera

  • Image Sensor : 2 × 1/1.8" Progressive Scan CMOS
  • Max. Resolution : 5120 × 1440
  • Min. Illumination : Color: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with light
  • Shutter Time : 1/3 s to 1/100,000 s
  • Angle Adjustment : Pan: 0° to 355°, tilt: 0° to 90°, rotate: 0° to 360°

Lens

  • Lens Type : Fixed focal lens, dual lens: 4 mm
  • Focal Length & FOV : 4 mm, horizontal FOV: 180°, vertical FOV: 44°
  • Lens Mount : M16
  • Iris Type : Fixed
  • Aperture : F1.0
  • Depth of Field : 3.6 m to ∞

DORI

  • DORI : 4 mm, D: 77 m, O: 30 m, R: 15 m, I: 7 m

Illuminator

  • Supplement Light Type : White Light
  • Supplement Light Range : Up to 40 m
  • Smart Supplement Light : Yes

Video

  • Main Stream
    • When WDR is On:
      • 50 Hz: 12.5 fps (5120 × 1440)
      • 60 Hz: 15 fps (5120 × 1440)
    • When WDR is Off:
      • 50 Hz: 20 fps (5120 × 1440)
      • 60 Hz: 20 fps (5120 × 1440)
  • Sub-Stream
    • When WDR is On:
      • 50 Hz: 12.5 fps (1920 × 536, 960 × 272)
      • 60 Hz: 15 fps (1920 × 536, 960 × 272)
    • When WDR is Off:
      • 50 Hz: 20 fps (1920 × 536, 960 × 272)
      • 60 Hz: 20 fps (1920 × 536, 960 × 272)
  • Video Compression
    • Main stream: H.265+/H.265/H.264+/H.264
    • Sub-stream: H.265/H.264/MJPEG
  • Video Bit Rate : 32 Kbps to 16 Mbps
  • H.264 Type : Baseline Profile, Main Profile, High Profile
  • H.265 Type : Main Profile
  • Bit Rate Control : CBR, VBR
  • Scalable Video Coding (SVC) : H.264 and H.265 encoding
  • Region of Interest (ROI) : 1 fixed region(s) for main stream

Audio

  • Audio Type : Mono sound
  • Audio Compression : G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
  • Audio Bit Rate : 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)
  • Audio Sampling Rate : 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
  • Environment Noise Filtering : Yes

Network

  • Protocols : TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP,
    UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv4/IPv6, UDP, Bonjour, SSL/TLS, ISUP, ARP,
    WebSocket, WebSockets
  • Simultaneous Live View : Up to 6 channels
  • API : Open Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK, ISUP
  • User/Host
    • Up to 32 users
    • 3 user levels: administrator, operator, and user
  • Security : Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-MD5), watermark, IP address filter, basic and digest authentication for
    HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface,
    RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.2, host authentication (MAC address)

Network Storage

  • NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR), NVR,
  • Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
  • Client : iVMS-4200, Hik-Connect, Hik-Central
  • Web Browser
  • Plug-in required live view: IE 10, IE 11,
  • Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+,
  • Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+


  • Image Parameters Switch : Yes
  • Image Settings : saturation, brightness, contrast, sharpness, gain, white balance, adjustable by client software or web browser
  • Day/Night Switch : Day, Night, Auto, Schedule
  • Wide Dynamic Range (WDR) : 130 dB
  • SNR : ≥ 52 dB
  • Image Enhancement : BLC, HLC, 3D DNR

Interface

  • Ethernet Interface : 1 RJ45 10 M/100 M self-adaptive Ethernet port
  • On-Board Storage : Built-in memory card slot, support microSD/microSDHC/microSDXC/TF card, up to 512GB
  • Built-in Microphone : Yes
  • Built-in Speaker : Max. power consumption: 1 W, max. sound pressure: 10 cm: 97 dB
  • Audio
    • 1 input (line in), terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7
      KΩ, interface type: non-equilibrium,
    • 1 output (line out), terminal block, max. output amplitude: 3.3 Vpp, output
      impedance: 100 Ω, interface type: non-equilibrium
  • Alarm : 1 input, 1 output (max. 24 VDC, 1 A)
  • Reset Key : Yes

Event

  • Basic Event : Motion detection (support alarm triggering by specified target types (human and
    vehicle)), alarm input and output, flashing alarm light output, audible alarm output,
    exception
  • Smart Event : Line crossing detection, intrusion detection, region entrance detection, region exiting
    detection (support alarm triggered by specified target types (human and vehicle)),
    scene change detection
  • Linkage : Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm
    output, trigger recording, trigger capture, audible warning, white light flashing

Deep Learning Function

  • Perimeter Protection : Line crossing, intrusion, region entrance, region exiting (support alarm triggering by specified target types (human and vehicle))

General

  • Power
    • 12 VDC ± 25%, 0.88 A, max. 10.5 W, Ø 5.5 mm coaxial power plug,
    • PoE: IEEE 802.3af, Class 3, 36 V to 57 V, 0.35 A to 0.22 A, max. 12.5 W
  • Material : Front cover: metal, body: metal, bracket: metal
  • Dimension : 118.6 mm × 105.1 mm × 305.4 mm (4.7" × 4.1" × 12")
  • Package Dimension : 405 mm × 190 mm × 180 mm (16" × 7.5" × 7.1")
  • Weight : Approx. 1420 g (3.1 lb.)
  • With Package Weight : Approx. 2228 g (4.9 lb.)
  • Storage Conditions : -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
  • Startup and Operating Conditions : -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
  • Language
    • 33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian,
      Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish,
      Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese,
      Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
      General Function Anti-flicker, heartbeat, password reset via email, password protection, one-key reset
  • Flashing Light : Yes

Downloads

Additional Information

Device Camera
Type ColorVu | Bullet | Network
