• High quality imaging with 2 MP, 1920 × 1080 resolution
• 2.8 mm and 6 mm fixed focal lens
• Up to 60 m IR distance for bright night imaging
• Up to 60 m white light distance for bright night imaging
• High quality audio with audio over coaxial cable, built-in mic
• One port for four switchable signals (TVI/AHD/CVI/CVBS）
• Water and dust resistant (IP67)
• Smart-Hybrid light, optimize your security with flexible lighting options

Camera

• Image Sensor : 2 MP CMOS
• Max. Resolution : 1920 (H) × 1080 (V)
• Min. Illumination : 0.01 Lux @ (F2.0, AGC ON), 0 Lux with white light
• Shutter Time : PAL: 1/25 s to 1/50,000 s; NTSC: 1/30 s to 1/50,000 s
• Day & Night : ICR
• Angle Adjustment : Pan: 0 to 360°, Tilt: 0 to 180°, Rotation: 0 to 360°
• Signal System : PAL/NTSC

Lens

• Lens Type : Fixed focal lens, 2.8 mm
• Focal Length & FOV : 2.8 mm, horizontal FOV: 101°, vertical FOV: 56°, diagonal FOV: 118°
• Lens Mount : M12

Illuminator

• Supplement Light Type : White Light;IR
• Supplement Light Range
  • IR : Up to 60 m
  • White Light : Up to 60 m


• Image Settings : Anti-Banding, Brightness, Sharpness, Smart IR
• Frame Rate
  • TVI: 1080P @ 30 fps, 1080P @ 25 fps
  • AHD: 1080P @ 30 fps, 1080P @ 25 fps
  • CVI: 1080P @ 30 fps, 1080P @ 25 fps
  • CVBS: PAL/NTSC
• Day/Night Mode : Auto/Color/BW (Black and White)
• Wide Dynamic Range (WDR) : Digital WDR
• Image Enhancement : DWDR/BLC/HLC/Global
• White Balance : Auto/Manual
• AGC : Yes

Interface

• Video Output : Switchable TVI/AHD/CVI/CVBS

General

• Power : 12 VDC ± 25%, max.9.8 W,*You are recommended to use one power adapter to supply the power for one camera.
• Material
  • Front cover: Metal
  • Main body: Plastic
• Dimension : 192.6 mm × 178.3 mm × 71 mm (7.58" × 7.02" × 2.8")
• Weight : Approx. 738 g (1.63 lb.)
• Operating Condition : -40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation)
• Communication : HIKVISION-C
• Language : English

Approval

• Protection : IP67
