• High quality imaging with 4 MP resolution
• Realizing Wi-Fi connection and easy installation
• Provides real-time security via built-in two-way audio
• EXIR 2.0, advanced infrared technology with long IR distance
• Support on-board storage up to 512 GB (SD card slot)
• Water and dust resistant (IP66)

Camera

• Image Sensor : 1/3" Progressive Scan CMOS
• Max. Resolution : 2560 × 1440
• Min. Illumination : Color: 0.5 Lux @ (F1.6, AGC ON),B/W: 0 Lux with IR
• Shutter Time : 1/25 s to 1/10000 s
• Day & Night : IR cut filter
• Angle Adjustment : Pan: 0° to 360°,tilt: 0° to 90°,rotate: 0° to 360°

Lens

• Lens Type : Fixed focal lens, 2.8 and 4 mm optional
• Focal Length & FOV : 2.8 mm, horizontal FOV 97°, vertical FOV 53°, diagonal FOV 117°
• Aperture : F1.6
• Iris Type : Fixed
• Lens Mount : M12
• Depth of Field : 2.8 mm: 1 m to ∞

DORI

• DORI : 2.8 mm, D: 63 m, O: 25 m, R: 12 m, I: 6 m

Illuminator

• Supplement Light Type : IR
• IR Wavelength : 850 nm
• Supplement Light Range : Up to 30 m
• Smart Supplement Light : Yes

Video

• Main Stream
  • 50 Hz:
    • 20 fps (2560 × 1440),
    • 25 fps (1920 × 1080, 1280 × 720)
  • 60 Hz:
    • 20 fps (2560 × 1440),
    • 30 fps (1920 × 1080, 1280 × 720)
  • Sub-Stream
    • 50 Hz: 25 fps (768 x 432, 512 × 288)
    • 60 Hz: 30 fps (768 x 432, 512 × 288)
• Video Compression
  • Main stream: H.265+/H.265/H.264+/H.264
  • Sub-stream: H.265/H.264/MJPEG
• Video Bit Rate : 256 Kbps to 4 Mbps
• H.264 Type : Baseline Profile,Main Profile,High Profile
• H.265 Type : Main Profile
• Bit Rate Control : CBR,VBR

Audio

• Audio Compression : G.711/G.722.1/G.726/PCM/AAC-LC
• Audio Bit Rate : 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/16 to 64 Kbps (AAC-LC)
• Audio Sampling Rate : 8 kHz/16 kHz
• Environment Noise Filtering : Yes

Network

• Protocols : TCP/IP, ICMP, HTTP, HTTPS, DHCP, DNS, RTP, RTSP, RTCP, NTP, IGMP, QoS, Bonjour
• Simultaneous Live View : Up to 4 channels
• APINA
• SecurityPassword protection, HTTPS encryption, Security Audit Log, basic and digest authentication for HTTP/HTTPS
• User/HostOnly one user: administrator
• Network Storage
  • NAS (NFS, SMB/CIFS),
  • Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
• Client : Hik-Connect, iVMS-4200
• Web Browser : NA

• Wi-Fi
• Transfer Rate : 11n: up to 300 Mbps
• Wi-Fi Protocol : 802.11n: OFDM,802.11b: DSSS,802.11g: OFDM
• Frequency Range : 2.412 GHz to 2.472 GHz
• Channel Bandwidth : 20 MHz
• Modulation : 802.11n: BPSK, QPSK, 16QAM, and 64QAM,802.11b: DBPSK and DQPSK, CCK,802.11g: BPSK, QPSK, 16QAM, and 64QAM
• Wireless Range
  • Up to 120 m(The performance varies based on actual environment)
  • Antenna : 2 Antennas


• Image Settings : Auto
• Day/Night Switch : Auto, Schedule, Day, Night
• Wide Dynamic Range (WDR) : 80 dB
• SNR : ≥ 52 dB
• Image Enhancement : BLC, 3D DNR

Interface

• Built-in Microphone : Yes
• Built-in Speaker : Yes
• On-Board Storage : Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
• Reset Key : Yes
• Ethernet Interface : 1 RJ45 10 M/100 M self-adaptive Ethernet port

Event

• Basic Event : Motion detection (support alarm triggering by specified target types (human and vehicle)), exception
• Linkage : Upload to NAS/memory card,notify surveillance center,trigger recording,trigger capture

General

• Power : 12 VDC ± 25%, 0.5 A, max. 6 W,Ø5.5 mm coaxial power plug,reverse polarity protection,A switching adapter is included in the package.
• Language : English
• Storage Conditions : -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
• General Function : Heartbeat, mirror, password protection
• Startup and Operating Conditions : -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
• Material : Front cover: metal, back cover: plastic
• Dimension : 175.6 mm × 73 mm × 89.1 mm (6.9" × 2.9" × 3.5")
• Package Dimension : 260 mm × 125 mm × 125 mm (10.2" × 4.9" × 4.9")
• Weight : Approx. 345 g (0.8 lb.)
• With Package Weight : Approx. 635 g (1.4 lb.)
