HKV DS-2DE2C400IWG/W (2.8MM)

SKU: HKV DS-2DE2C400IWG/W (2.8MM)

BRAND: Hikvision


Hikvision Fixed Outdoor IR WIFI Stand Alone PT Network Camera 4MP 2.8mm Lens , 30m IR , 1/2.9" CMOS , Built-in Microphone & Speaker , Support Human & Vehicle Detection & Auto-Tracking Lite , 1xRJ45 10M/100M , WDR , WPA-PSK/WPA2-PSK , ONVIF, SDK , 12VDC/1A

Fixed Outdoor IR WIFI Stand Alone PT Network Camera

Feature(s)

  • High quality imaging with 4 MP resolution
  • Support Human Detection, Vehicle Detection, and Auto-tracking Lite
  • EXIR 2.0, advanced infrared technology with long IR distance
  • Hik-Connect cloud service and app for remote management and views of devices
  • Built-in microphone and speaker for real-time audio security
  • Built-in memory card slot, support microSD/SDHC/SDXC card, up to 512 GB
  • Water and dust resistant (IP66)

Specifications

Camera

  • Image Sensor : 1/2.9" Progressive Scan CMOS
  • Max. Resolution : 2560 × 1440
  • Min. Illumination : Color: 0.01 Lux @ (F1.6, AGC ON),B/W: 0.005 Lux @ (F1.6, AGC ON),0 Lux with IR

Lens

  • Focal Length : 2.8 mm
  • FOV : 2.8 mm,horizontal FOV 91°, vertical FOV 49°, diagonal FOV 108°
  • Aperture : F1.6

Illuminator

  • Supplement Light Type : IR
  • Supplement Light Range : IR distance: up to 30 m
  • IR Wavelength : 850 nm

PTZ

  • Movement Range (Pan) : 0° to 345°
  • Movement Range (Tilt) : 0° to 80°
  • Pan Speed : Up to 25°/s
  • Tilt Speed : Up to 20°/s

Video

  • Main Stream
    • 50 Hz: 20 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
    • 60 Hz: 20 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
  • Sub-Stream
    • 50 Hz: 25 fps (1280 × 720, 768 × 432, 512 × 288)
    • 60 Hz: 30 fps (1280 × 720, 768 × 432, 512 × 288)
  • Video Compression
    • Main stream: H.265/H.264,
    • Sub-stream: H.265/H.264
  • Video Bit Rate : 256 Kbps to 2 Mbps
  • H.264 Type : Baseline profile,Main profile,High profile
  • H.265 Type : Main profile

Audio

  • Audio Compression : G.711,AAC-LC
  • Audio Bit Rate : 64 Kbps (G.711ulaw/G.711alaw), 16 to 64 Kbps (AAC-LC)
  • Audio Sampling Rate : 8 kHz,16 kHz
  • Environment Noise Filtering : Yes

Network

  • Protocols : TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,RTP,RTSP,RTCP,NTP,UPnP,IGMP,QoS,IPv4,IPv6,UDP,Bonjour,SSL/TLS
  • API : ONVIF, SDK
  • Security : Password protection,HTTPS encryption,security audit log,basic and digest authentication for HTTP/HTTPS,TLS 1.1/1.2, WSSE for Open Network Video Interface

Wireless (Wi-Fi)

  • Encryption Mode : WPA-PSK/WPA2-PSK
  • Wi-Fi Protocols : IEEE802.11b,IEEE802.11g,IEEE802.11n
  • Frequency Range : 2.412 GHz to 2.472 GHz
  • Channel Bandwidth : 20 MHz
  • Modulation
    • 802.11b: CCK, QPSK, BPSK,
    • 802.11g: OFDM ,
    • 802.11n: OFDM
  • Transfer Rate : 11b: up to 54 Mbps,11g: up to 54 Mbps,11n: up to 150 Mbps
  • Wireless Range Up to 50 m (The performance varies based on actual environment)


  • Image Settings : Saturation, brightness, contrast, and sharpness adjustable by client software
  • Wide Dynamic Range (WDR)Digital WDR

Interface

  • Ethernet Interface : 1 RJ45 10 M/100 M self-adaptive Ethernet port
  • Built-in Microphone : 1 built-in microphone
  • On-board Storage : Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
  • Built-in Speaker : 1 built-in speaker

Event

  • Basic Event : Motion detection (support alarm triggering by specified target type (human and vehicle)), exception
  • Linkage : Upload to memory card, notify surveillance center, trigger capture, audible warning, auto-tracking lite

Deep Learning Function

  • Perimeter Protection
    • Line crossing, intrusion, region entrance, region exiting
    • Support alarm triggered by specified target types (human and vehicle)

General

  • Power : 12 VDC ± 10%, 1 A, max. 10 W, Ø2 mm coaxial power plug, reverse polarity protection
  • Dimension : 163.9 mm × 185.8 mm × 131.9 mm (6.45" × 7.31" × 5.19")
  • Weight : Camera weight: 565 g (1.25 lb.) With package weight: 1020 g (2.25 lb.)
  • Material : Plastic
  • Operating Condition : -30 °C to 50 °C (-22 °F to 122 °F). Humidity 95% or less (non-condensing)
  • General Function : heartbeat, mirror

Downloads

Additional Information

Device Camera
Type Fixed Outdoor | IR | WIFI | Stand Alone | PT | Network
