HKV DS-9664NXI-I8/S

SKU: HKV DS-9664NXI-I8/S

BRAND: Hikvision


Hikvision 64CH AcuSense 4K NVR H.265/H.264/H.264+/MPEG4, 32 MP/24 MP/12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/72,8xSATA, 2xUSB2.0, 2xRJ45, 1xUSB 3.0, 2xHDMI, 2xVGA,1xeSATA Interface, Up to 10TB Cap for each HDD,100~240 VAC, 50/60 Hz, 30W, 442×459×92mm

AcuSense Series NVR

Feature(s)

  • H.265+/H.265/H.264+/H.264 video formats
  • Intelligent analytics based on deep learning algorithm
  • Up to 4-ch perimeter protection
  • Up to 1-ch facial recognition for video stream, or up to 4-ch facial recognition for face picture
  • Up to 16/32/64-ch IP camera inputs
  • Up to 16-ch 1080p decoding capability
  • Up to 320 Mbps incoming bandwidth

Specifications

Facial Recognition

  • Facial Detection And Analytics : Face picture comparison, human face capture, face picture search
  • Face Picture Library : Up to 16 face picture libraries, with up to 10,000 face pictures in total (each picture ≤ 15KB, total capacity ≤ 150 MB)
  • Facial Detection And Analytics Performance : 1-ch human face capture (HD network camera, up to 8 MP, H.264/H.265)
  • Face Picture Comparison : 4-ch face picture comparison alarm

Motion Detection 2.0

  • Human/Vehicle Analysis : 32-ch

Perimeter Protection

  • Human/Vehicle Analysis
    • Up to 4-ch 2 MP (H.264/H.265) video analysis for human and vehicle recognition;
    • Up to 12 rules in total

Recording

  • Dual-Stream : Support
  • Audio Compression : G.711ulaw/G.711alaw/G.722/G.726/MP2L2/AAC

Video And Audio

  • IP Video Input :
    • 64-ch
    • Up to 12 MP resolution
    • *: 32 MP and 24 MP is only available for channel 1 when ultra HD resolution mode is enabled.
  • HDMI 1 Output : 4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
  • HDMI 2 Output : 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
  • VGA 1 Output : 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
  • Video Output Mode : HDMI1/VGA simultaneous output, HDMI2/VGA independent output
  • Incoming Bandwidth : 320 Mbps
  • Outgoing Bandwidth : 256 Mbps
  • Two-Way Audio : 1-ch, RCA (2.0 Vp-p, 1 KΩ)

Decoding

  • Decoding Format : H.265+/H.265/H.264+/H.264/MPEG4
  • Decoding Capability : 16-ch@1080p (30 fps)
  • Synchronous Playback : 64-ch
  • Stream Type : Video, Video & Audio

Network

  • Network Protocol : TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS
  • Remote Connection : 128
  • Network Interface : 2, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface

RAID

  • RAID Type : RAID0, RAID1, RAID5, RAID6, RAID10

Auxiliary Interface

  • SATA : 8 SATA interfaces
  • ESATA : 1 eSATA interface
  • Capacity : Up to 10 TB capacity for each disk
  • Serial Interface : RS-485 (full-duplex), RS-232, Keyboard
  • USB Interface : Front panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0
  • Alarm In/Out : 16/8

General

  • Power Supply : 100 to 240 VAC, 50 to 60 Hz
  • Consumption : ≤ 30 W
  • Working Temperature : -10 °C to 55 °C (14 °F to 131 °F)
  • Working Humidity : 10% to 90%
  • Chassis : 2U chassis
  • Dimension (W × D × H) : 442 × 459 × 92 mm (17.4"× 18" × 3.6")
  • Weight : ≤ 8.7 kg (19.2 lb.)

Downloads

Additional Information

Device NVR
Type AcuSense | Series
