• 2 MP HD video intercom function
• Access control function
• Noise suppression and echo cancellation
• Low illumination
• Tampering alarm supported
• Fisheye camera with IR supplement light
• Supports sub-modules’ access (max. 7)
• Nametag customization
• Easy to and extend

System parameters

• Operation system : Linux
• ROM : 32 MB
• RAM : 256 MB
• Processor : Embeded high performance processor

Display parameters

• Video parameters
• Lens : 2 MP HD camera
• Resolution : 2 MP
• FOV : Horizontal: 146°, Vertical: 82°
• Wide dynamic range (WDR) : Support
• Supplement light : Low illumination, IR supplement lights
• Video compression standard : H.264; H.265; MJPEG

Audio parameters

• Audio input : 1 built-in omnidirectional microphone
• Audio compression standard : G.711 U、G.711 A、Opus、AAC-LD、AAC-LC、G.726、G.722.1
• Audio output : 1 built-in loudspeaker
• Audio compression bitrate : 64 Kbps
• Audio quality : Noise suppression and echo cancellation
• Volume adjustment : Adjustable

Capacity

• User capacity : 2000
• Linked indoor station capacity : 500
• Sub door station capacity : 16

Network parameters

• Network protocol : TCP/IP, RTSP, , ipv6, onvif
• 3G/4GNA

Device interfaces

• Alarm input : 4 (2 exit buttons and 2 door contacts by default)
• Network interface : 1 RJ-45, 10/100 Mbps self-adaptive
• TAMPER : 1
• Exit button : 2 (2 for lock control)
• RS-4851 (1 for Hikvision's sub module communication)
• Lock control : 2 relays, Max. 30 VDC, 2 A
• Door contact input : 2

General

• Button : 1
• Installation : Surface mounting, flush mounting
• Net weight: 380 g
• Gross weight: 541 g
• Protective level : IP65
• Working temperature : -40 °C to 60 °C (-40 °F to 140 °F)
• Power supply : 12 VDC, 500 mA, IEEE 802.3af, PoE
• Application environment : Outdoor
• Power consumption : ≤ 5 W
• Language : English, Arabic, European French, Russian, European Spanish, Latin American Spanish, Italian, German, Polish, Turkish, Portuguese, Brazilian Portuguese, Uzbek, Kazakh, Czech, Hungarian, Dutch, Romanian, Bulgarian, Ukrainian, Croatian, Serbian, Greek, Lithuanian, Estonian, Latvian, Norwegian, Danish, Slovenian, Slovak, Hebrew, Swedish, Finnish, Mongolian, Vietnamese, Traditional Chinese (Taiwan), Latin American Spanish
