Camera
|
|
|
|
Image Sensor
|
1 / 2.8 "CMOS
|
|
|
|
Image Size
|
3840×2160
|
|
|
|
Electronic Shutter
|
1 / 3s ~ 1 / 100000s
|
|
|
|
Iris Type
|
Fixed Iris
|
|
|
|
Min. Illumination
|
0.02 lux @F1.6, AGC ON; 0 lux with illumination on
|
|
|
|
Lens
|
2.8mm@F1.6, Horizontal FoV: 106°;Vertical FoV:57°;Diagonal FoV:124°
|
|
|
|
Focus
|
Fixed
|
|
|
Lens Mount
|
M12
|
|
|
|
|
|
|
|
Day&Night
|
ICR
|
|
|
|
|
|
|
|
Wide Dynamic Range
|
120dB
|
|
|
|
|
|
|
|
BLC
|
Yes
|
|
|
|
|
|
|
|
HLC
|
Yes
|
|
|
|
|
|
|
|
Digital NR
|
Yes
|
|
|
|
|
|
|
|
Defog
|
Yes
|
|
|
|
|
|
|
|
S/N Ratio
|
≥50dB
|
|
|
|
|
|
|
|
Angle Adjustment
|
Pan: 0°~360°; Tilt:0°~75°;Rotation: 0°~360°
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Video Compression
|
Main stream: H.265+ / H.265 / H.264+ / H.264
Sub /Third stream: H.265+ / H.265 / H.264+ / H.264 / MJPEG
|
|
|
|
|
|
|
|
H.265 Compression Standard
|
Main Profile@Leve4.1 High Tier
|
|
|
Resolution
|
8MP(3840×2160),6MP(3200×1800), 4MP(2688×1520), 2K(2560×1440), 1080P (1920×1080),
720P (1280×720), D1, VGA (640×480), 640× 360, 480× 240, CIF
|
|
|
|
|
|
|
|
Main Stream
|
8MP(1~20fps) /6MP/4MP/2K/1080P (60Hz: 1~30fps; 50Hz: 1~25fps)
|
|
|
Sub Stream
|
1080P (60Hz:1~15fps; 50Hz:1~12fps)/
720P/D1/VGA/640×360/CIF/480× 240 (60Hz: 1~30fps; 50Hz: 1~25fps)
|
|
|
|
|
|
|
|
Third Stream
|
720P/D1/640×360/CIF (60Hz: 1~30fps; 50Hz: 1~25fps)
|
|
|
Bit Rate
|
64 Kbps ~12Mbps
|
|
|
|
|
|
|
|
Bit Rate Type
|
VBR / CBR
|
|
|
|
|
|
|
|
Image Settings
|
ROI, Saturation, Brightness, Hue, Contrast, Wide Dynamic, Sharpness, Image Mirror, Image Flip, NR, etc.
adjustable through client software or web browser
|
|
|
|
|
|
|
|
Audio Compression
|
G711A/U
|
|
|
ROI
|
8ROI, Each ROI to be configured separately
|
|
|
|
|
|
|
|
Interfaces
|
|
|
|
|
|
|
|
Network
|
RJ45 (10/100 Base-T)
|
|
|
|
|
|
|
|
Video Output
|
No
|
|
|
|
|
|
|
|
Audio
|
1CH audio input; 1CH built-in MIC
|
|
|
|
|
|
|
|
Storage
|
Built-in micro SD card slot, up to 256GB
|
|
|
|
|
|
|
|
Reset
|
Yes
|
|
|
|
|
|
|
|
Functions
|
|
|
|
|
|
|
|
Remote Monitoring
|
Web browser /TVT NVR/NVMS2.X/Mobile APP
|
|
|
|
|
|
|
|
Web Browser
|
Chrome 105.0+/Edge 105.0+/Firefox 121.0+/Safari 14.0+
|
|
|
|
|
|
|
|
Online Connection
|
Support simultaneous monitoring for up to 10 users; Support multi-stream real time transmission
|
|
|
|
|
|
|
|
Network Protocol
|
UDP, IPv4, IPv6, DHCP, NTP, RTSP, RTP, RTCP, RTMP, PPPoE, DDNS, SMTP, FTP,
802.1x, SNMP, UPnP, HTTP, HTTPS, HTTP POST, NAT, QoS
|
|
|
|
|
|
|
|
Interface Protocol
|
ONVIF
|
|
|
API&SDK
|
Yes
|
|
|
|
|
|
|
|
Storage
|
Network remote storage; micro SD card storage
|
|
|
|
|
|
|
|
Smart Alarm
|
Motion detection, SMD, SD card full, SD card error, IP address conflict, cable disconnection, video exception
(scene change, video blur and abnormal color detection)
|
|
|
|
|
|
|
|
Smart Event
|
Line crossing /region intrusion detection(human/vehicle classification), abandoned/missing object detection
|
|
|
General Function
|
Watermark, IP address filtering, video mask, heartbeat, smart supplement light, corridor pattern,
image distortion correction, ANR, cloud upgrade, disarming
|
|
|
|
|
|
|
|
PoE
|
Yes (IEEE802.3af)
|
|
|
Supplement Light Range
|
IR range: 20 ~ 30 m; white light range:20 ~ 30 m
|
|
|
|
|
|
|
|
Ingress Protection
|
IP67
|
|
|
|
|
|
|
|
Security
|
Video encryption, firmware encryption, configuration encryption, illegal login lock, IP address filtering,
802.1x authentication, basic and digest authentication for HTTP/RTSP/API
|
|
|
|
|
|
|
|
DORI Distance
|
|
|
Lens
|
Detect
|
Observe
|
Recognize
|
Identify
|
|
|
|
|
|
|
|
2.8mm
|
79m(259ft)
|
32m(105ft)
|
16m(52ft)
|
8m(27ft)
|
|
|
|
|
|
|
|
Others
|
|
|
|
|
|
|
|
Power Supply
|
DC12V/PoE
|
|
|
|
|
|
|
|
Power Consumption
|
DC12V: < 6.7W; PoE: <8.3W
|
|
|
|
|
|
|
|
Storage Conditions
|
- 30 °C ~ 65°C (-22°F~149°F), Humidity: less than 95 % (non-condensing)
|
|
|
|
|
|
|
|
Operating Conditions
|
- 30 °C ~ 60 °C (-22°F~140°F), Humidity: less than 95 % (non-condensing)
|
|
|
|
|
|
|
|
Dimensions ( mm )
|
Φ 94.6 × 82.8
|
|
|
|
|
|
|
|
Weight ( net )
|
Approx. 0.45KG
|
|
|
|
|
|
|
|
Material
|
Aluminum alloy body
|
|
|
|
|
|
|
|
Installation
|
Ceiling mounting; wall mounting
|
|
|
|
|
|
|
|
Certificate
|
CE, FCC
|
|
|
|
|
|
|
|
Environmental Protection
|
Complies with Directive EU RoHS, WEEE(2012/19/EU) , directive 94/62/EC and REACH(EC1907/2006)
|
|
|
|
|
|
|
