Ubiquiti UISP - AirMAX- NanoStation 5AC Loco, Gain:13dBi , Memory:64 MB DDR2, Data Rate:867Mbps, Ethernet Ports:1x10/100/1000Mbps , Max Power Consumption:8.5W, No POE Injector, Operating System:airOS, 5GHz
UISP - AirMAX- NanoStation
Overview
The NanoStation AC Loco features integrated airMAX (MIMO TDMA protocol) technology and dedicated Wi-Fi management. The low cost, high performance, and small form factor of the NanoStation AC Loco makes them extremely versatile and economical to deploy. It also features the classic NanoStation design with updated proprietary airMAX ac chipset. NO PoE Injector
Features
- Ubiquiti Networks set the bar for the world's first low-cost and efficient broadband Customer Premises Equipment (CPE) with the NanoStation® M.
- The NanoStation AC and NanoStation AC loco take the same concept to the future with sleek form factors, along with integrated airMAX (MIMO TDMA protocol) technology and dedicated Wi-Fi management.
- The radio and antenna are combined to create a more efficient and compact CPE. The NanoStation AC and NanoStation AC loco get maximum gain out of the smallest footprint.
- The low cost, high performance, and small form factor of the NanoStation AC and NanoStation AC loco make them extremely versatile and economical to deploy.
Specifications
- Dimensions With Mount Without Mount
- 257 x 84 x 30 mm (10.12 x 3.31 x 1.18")
- 257 x 84 x 41 mm (10.12 x 3.31 x 1.61")
- Weight ; 233 g (8.22) oz
- Power Supply : 24V, 0.5A Gigabit PoE Supply (Included)
- Max. Power Consumption : 8.5W
- Power Method
- 802.3af Alternative A (Pairs 1, 2+; 3, 6 Return)
- 24V Passive PoE (Pairs 4, 5+; 7, 8 Return)
- Gain : 16 dBi
- Networking Interface : (2) 10/100/1000 Mbps Ethernet Ports
- Channel Bandwidths : 10/20/30/40/50/60/80 MHz
- Processor Specs Atheros MIPS 74Kc, 560 MHz
- Memory : 64 MB DDR2
- Cross-pol Isolation : 20 dB Minimum
- Max. VSWR : 1.6:1
- Beamwidth : 45° (H-pol) / 45° (V-pol) / 45° (Elevation)
- Polarization : Dual Linear
- Enclosure : UV Resistant Polycarbonate
- LEDs : (1) Power, Eth1, Eth2; (1) Signal Strength
- Mounting : Pole-Mount (Kit Included)
- Operating Temperature : -40 to 70° C (-40 to 158° F)
- Operating Humidity : 5 to 95% Noncondensing
- RoHS Compliance : Yes
- ESD/EMP Protection : ±24kV Contact/Air
- Shock & Vibration : ETSI300-019-1.4
- Certifications : CE, FCC, IC
Downloads
Additional Information
| Device |
NanoStation |
| Type |
UISP | AirMAX |
Experience high-speed connectivity with the Ubiquiti NanoStation 5AC Loco. Featuring a compact design and 13dBi gain, this reliable device delivers fast data rates up to 867Mbps, making it ideal for seamless streaming and gaming. Its efficient airMAX technology ensures versatile deployment in any environment, providing outstanding performance without breaking the bank.
