Voltronic Power Inverter MKS 1000VA/1000W 24VDC O/P 230VAC Pure Sine Wave, 25A MPPT, MAX PV ARRAY 600W, Max Charge Current 45A, MAX PV ARRAY OCV:75VDC, Surge Power 2000VA, MPPT Operating Voltage:30-66VDC, 100x272x355, 7kg
Power Inverter MKS
Feature
Pure sine wave inverter
Output power factor 1
Built-in MPPT solar charge controller
Selectable charging current based on applications
Configurable AC/Solar input priority via LCD setting
Compatible to AC mains or generator power
Battery equalization for optimized battery performance and lifecycle
Specifications
Rated Power : 1000VA/1000W Parallel Capability : No
Input
Voltage : 230V AC
Selectable Voltage Range : 170-280V AC (For Personal Computers) ; 90-280V AC (For Home Appliances)
Frequency Range : 50Hz / 60Hz (Auto sensing)
Output
AC Voltage Regulation (Batt Mode) : 230V AC ±5%
Surge Power : 2000VA for 5 seconds
Efficiency (Peak) : 90%
Transfer Time : 10ms (Personal computers) ; 20ms (Home appliances)
Waveform : Pure sine wave
Battery
Battery Voltage : 24V DC
Floating Charge Voltage : 27V DC
Overcharge Protection : 31V DC
Solar Charger & AC Charger
Maximum PV Array Power : 600W
MPPT Range @ Operating Voltage : 30-66V DC
Maximum PV Array Open Circuit Voltage : 75V DC
Maximum Solar Charge Current : 25A
Maximum AC Charge Current : 20A
Maximum Charge Current : 45A
Physical
Dimensions D X W X H : 100 X 272 X 355
Net Weight (kgs) : 7.0kg
Environment
Humidity : 5% to 95% relative Humidity (Non-condensing)
Experience reliable power with the VP MKS 1K MCR inverter, featuring pure sine wave technology for optimal device compatibility. With a built-in MPPT solar charge controller and 1000W output, this inverter ensures efficient energy use and improved battery life. Perfect for both home and solar applications, it guarantees uninterrupted power supply wherever you need it.
