RM 21-21 230 V AC
SKU: RM 21-21 230 V AC
BRAND: Metz Connect
R 626.75 (inc VAT) R 545.00 (ex VAT)
🚚
Delivery time: 2-5 working days for South Africa
✓
In stock - Ready for immediate dispatch
Free shipping for orders over R1,000.00
Relay Module For Electrical Isolation Between Logic And Load With Screw Terminal Mounting Base And LED Status Indicator 230VAC 2c/o 8A/250VAC 32,5Kohm
Relay Module
Specifications
Product Type: Interface Relay Module
Model Number: RM 21-21 230 V AC
Manufacturer Part Number: 11050705
Rated Operating Voltage: 230 V AC
Current Consumption: 3.3 mA at 230 V AC
Nominal Coil Power: 0.76 VA
Typical Power Loss: 2.4 W
Number of Contacts: 2 changeover contacts (DPDT)
Contact Material: Silver-nickel (AgNi 90/10)
Maximum Switching Voltage: 250 V AC
Rated Continuous Current: 8 A
Maximum Switching Capacity: 2,000 VA (AC-1)
Maximum Switch-On Current: 15 A for up to 4 seconds
Minimum Switching Load: 5 V DC / 10 mA
Switching Frequency: Up to 360 switching cycles per hour
Mechanical Service Life: 5 million switching cycles
Electrical Service Life: 1 million switching cycles
Status Indicator: Red LED
Connection Type: Screw terminals
Maximum Conductor Cross-Section: 2 × 2.5 mm²
Mounting Type: 35 mm DIN rail
Dimensions (W × H × D): 15.5 × 75 × 65 mm
Weight: Approximately 95 g
Operating Temperature: −20°C to +55°C
Storage Temperature: −25°C to +70°C
Application: Electrical isolation between control logic and load circuits in industrial automation, control panels and switching systems.
Downloads
Additional Information
Device
Module
Type
Relay | Module
Enhance your industrial automation with the RM 21-21 230 V AC relay module. Designed for reliable electrical isolation, this interface relay features screw terminal mounting and a convenient LED status indicator, ensuring optimal performance in control panels and switching systems. With a robust capacity of 8A and 2 million switching cycles, it’s the perfect choice for efficient load management and enhanced system safety.
