BATT 12V12 PSS

SKU: BATT 12V12 PSS

BRAND: PSS


Rechargeable Battery 12V12AH (L=151 W=98 H=101mm) F2 Terminal 6.35mm 3.6kg

Rechargeable Battery 12V12AH

Specifications

    • Nominal Voltage : 12V
    • Rated Capacity : 12Ah
    • Dimensions
      • Total Height : 3.98 inches (101mm)
      • Height : 3.74 inches (95mm)
      • Length : 5.95 inches (151mm)
      • Width : 3.86 inches (98mm)
    • Approximate Weight : 7.92 lbs. (3.6kg)

Characteristic

  • Capacity 77°F(25°C)
    • 20h rate : 12Ah
    • 10h rate : 11.2Ah
    • 5h rate : 10.1Ah
    • 1h rate : 7.49Ah
    • 15 min rate : 5.52Ah
  • Internal Resistance
    • Full Charged Battery 77°F(25°C) : Approx. 20mΩ
  • Capacity Affected by Temperature (20h rate) :
    • 104°F(40°C) : 102%
    • 77°F(25°C) : 100%
    • 32°F(0°C) : 85%
    • 5°F(-15°C) : 65%
    • .
  • Self-Discharge 68°F(20°C) (Capacity after)
    • 3 month storage : 90%
    • 6 month storage : 80%
    • 12 month storage : 60%
  • Max. Discharge Current 77°F(25°C) : 180A(5s)
  • Terminal : T2
  • Charge (Constant Voltage,25°C)
    • Cycle : 14.5~14.9V(-24mV/°C) max. current:3.6 A
    • Float : 13.6~13.8V(-18mV/°C)

Downloads

Additional Information

Device Battery
Type Rechargeable | 12V12AH
