• High protective level: IP65 and IK08
• Slim and flexible design with metal
• 3,000 fingerprints, 10,000 cards and 100,000 events storage
• Built-in card reader for M1 card
• Supports operation by mobile App (Hik-Connect)
• Supports AP configuration, configuration via PC web and mobile web are available
• Supports multiple authentication types: card, fingerprint, PIN, and bluetooth

System

• Operating system: Linux

Audio

• Audio output: 1 built-in buzzer

Network

• Bluetooth: Support
• Wired network: 10/100 Mbps self-adaptive
• Wi-Fi: 2.4 GHz, IEEE 802.11b / 802.11g / 802.11n / 802.11d / 802.11e / 802.11h / 802.11i

Interface

• RS-485: 1, supports OSDP
• Network interface: 1
• Wiegand: Wiegand 26/34
• Lock control: 1
• Exit button: 1
• Door contact input: 1
• Alarm input: 2
• Alarm output: 1
• TAMPER: 1

Capacity

• Card capacity: 10,000
• Fingerprint capacity: 3,000
• Event capacity: 100,000

Authentication

• Card type: M1 card
• Card reading distance: 0 to 4 cm
• Card reading duration: ＜ 1 s
• Fingerprint module: Optical fingerprint module
• Fingerprint comparing mode: 1:1 and 1:N
• Fingerprint recognition duration: ＜ 1 s

General

• Power supply: 12 VDC / 1 A
• Working temperature: −30 °C to 60 °C (−22 °F to 140 °F)
• Working humidity: 0% to 90% (no condensing)
• Dimensions: 57.7 mm × 177 mm × 34.6 mm (2.3" × 7.0" × 1.4")
• Power consumption: ≤ 12 W
• Language: English, Vietnamese, Brazilian Portuguese, Spanish, French, Italian, Arabic, Thai, Turkish, Indonesian, Ukrainian, Russian

Function

• Hik-Connect: Support
• Configuration via web browser: Support PC web configuration and mobile web operation
