LIF480-10B24R2

Name: LIF480-10B24R2 - Communica [Part No: LIF480-10B24R2]
Brand: Mornsun
SKU: LIF480-10B24R2
Price: 2364.50 ZAR
Availability: InStock

SKU: LIF480-10B24R2

BRAND: Mornsun

In Stock
R 2,719.18_{(inc VAT)}
R 2,364.50_{(ex VAT)}

Collections: Power

Type: Power Supplies

Category: Din Rail Power Supply, Switch Mode Power Supplies

DIN Rail Metal Case Slim Profile Switch Mode Power Supply with Active PFC. Input: 85 ~ 264VAC/120 - 370VDC. Output 24VDC @ 20A Hi Reliability

Slim Profile Switch Mode Power Supply

Feature

Universal 85- 264VAC or 120- 370VDC Input voltage
Accepts AC or DC input (dual-use of same terminal)
Operating ambient temperature range: -40℃ to +70℃
The efficiency is up to 94.5%
High I/O isolation test voltage up to 3000VAC
DC OK function
Active PFC, PF > 0.99
Low ripple & noise
Output short circuit, over-current, over-voltage,
over-temperature protection, input undervoltage
protection
DIN rail TS-35/7.5 or 15 mountable
Ultra slim design with 48mm width
Withstand 305VAC input voltage 5S
Safety according to IEC/UL62368, EN61558

Additional Information

Device	Power Supply
Type	Slim Profile \| Switch Mode
Input Voltage	85 ~ 264VAC/120 - 370VDC
Output	24VDC @ 20A
Size	W-48mm x H-132mm x D-125mm
