LMF200-23B48

SKU: LMF200-23B48

BRAND: Mornsun


Metal Case Switch Mode Power Supply with Active PFC. Input: 85 ~ 305VAC/120 - 430VDC. Output 48VDC @ 4,2A. 4KVAC Isolation

Metal Case Switch Mode Power Supply

Feature

  • Universal 85 - 305VAC or 120 - 430VDC Input voltage
  • Accepts AC or DC input (dual-use of same terminal)
  • Operating temperature range: -30℃ to +70℃
    Built-in active PFC function
  • High I/O isolation test voltage up to 4000VAC
  • Output short circuit, over-current, over-voltage,
    over-temperature protection
  • LED indicator for power on
  • Emissions meets CISPR32/EN55032 CLASS B
  • Start-up delay time less than 5 seconds at -30℃
  • Operating altitude up to 5000m
  • Safety according to IEC/UL62368-1

Downloads

Additional Information

Device Power Supply
Type Metal Case | Switch Mode
Input Voltage 85 ~ 305VAC/120 - 430VDC
Output 48VDC @ 4,2A
Size 215.00 x 115.00 x 30.00m
