Mechanical

• Dimensions : 191.7 x 185 x 43.7 mm (7.55 x 7.28 x 1.72")
• Weight : 1.2 kg (2.65 lb)

Hardware

• Total non-blocking line rate : 16 Gbps
• Max. power consumption : 15W
• Power method : Universal AC input: 100—240V AC
• Power supply Internal 60W AC/DC power supply
• Networking interface : (16) 10/100/1000 MbE RJ45
• PoE Interface : (8) PoE/PoE+ (Pins 1, 2+; 3, 6-)
• Managementinterface : EthernetIn-Band
• Max PoE+ wattage per port by PSE : 30W
  PoE budget : 45W
• Modes : SMB layer 2 PoE GbE switch
• Operating temperature : -15 to 40° C (5 to 104° F)
• Operating humidity : 10 to 90% noncondensing
• Certifcations : CE, FCC, IC

LEDs

• System
  • (1) Power: blue/white
  • Flashing white: bootup in progress
  • Flashing blue:
  • rmware upgrading
  • Steady white: factory defaults, awaiting adoption
• Steady blue: device is adopted
• Ethernet
  • Green: 1G
  • Amber: 10/100 Mbps
• PoE : Amber: PoE/PoE+

1. Datasheet - UBQ USW-LITE-16-POE
