CAN FD Performance and Serial Compatibility

The USR-CAN316 is an industrial-grade, DIN-rail-mount protocol converter designed for bidirectional communication between the CAN FD (Flexible Data-Rate) bus and RS485/RS232 serial interfaces . The device supports the CAN FD protocol, offering extremely fast transmission speeds (up to 5 Mbps) and increased data volume (up to 64 bytes in a single frame). It is fully backward compatible to the CAN 2.0A/2.0B standard , facilitating system migration and integration.

Modbus RTU gateway and advanced operating modes

The USR-CAN316 converter functions as a Modbus RTU Gateway , enabling CAN/CAN-FD data to be transmitted to Modbus RTU (Master/Slave) via RS485/RS232. It offers five flexible conversion modes , including transparent, standard, and Modbus protocol conversion. The device supports 32 software-configurable filter sets , allowing for precise traffic management within the CAN network.

Reliability and industrial power supply

The device provides high reliability thanks to a wide operating temperature range of -40°C to +85°C and EMC Level 3 protection . It features dual watchdog and two built-in 120Ω terminating resistors for the CAN bus. It is powered by a wide DC voltage of 9-36V with reverse polarity protection, and is DIN rail -mountable .

• communication interfaces: 1 x CAN (supports CAN-FD) and 1 x RS485/RS232 (software selectable, terminal block)
• CAN FD speed:  data domain up to 5 Mbps . arbitration domain up to 1 Mbps
• resistance:  two built-in 120 Ω terminating resistors for the CAN bus (configurable)
• Modbus Gateway:  CAN(FD) to Modbus RTU (Master/Slave) conversion. Supports 64 receive and 64 transmit messages.
• reliability:  operating temperature -40°C ~ +85°C . EMC protection Level 3. Power supply DC 9-36V

The set includes:

• 1 x USR-CAN316 CAN-FD Converter
• 1 x original packaging

1. Datasheet - USR CAN316 CANFD TO RS485/RS232
